| Brand Name : | ITI-LINK |
| Model Number : | ITI-CT5SF-017 |
| Certification : | UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS |
| Delivery Time : | 15-45Days |
| Payment Terms : | T/T |
| Supply Ability : | 2000pcs/day |
1.The SFTP Ethernet network cable, specifically the Cat5e SFTP 24AWG Copper 500Ft Yellow PVC Jacket Shielded Ethernet Cable, is perfect for use in a variety of different settings, including home and office networks, data centers, server rooms, and more. The cable is rated for frequencies of up to 100MHz, which means that it is capable of handling even the busiest networks with ease.
2.The Cat5e SFTP cable features a durable yellow jacket that is
easy to identify and stands up to the wear and tear of daily use.
The jacket is made of PVC. With a length of 500 feet, it provides
great flexibility in network setup. The jacket also meets relevant
safety standards for use in various environments.
3.The conductor gauge of the cable is 24 AWG, and it is made of
copper. This standard for Ethernet cables provides a good balance
of performance and cost, making it the ideal choice for most
network applications.
4.Whether you are setting up a new network or upgrading an existing
one, the Cat5e SFTP cable is an excellent choice. It provides
reliable performance, excellent shielding, and a durable yellow PVC
jacket that will stand up to years of use. Order yours today and
experience the difference that this high - quality Ethernet cable
can make.
This Cat5e SFTP 24AWG Copper 500Ft Yellow PVC Jacket Shielded
Ethernet Cable is a high - quality Ethernet patch cord, especially
designed to offer fast and reliable connectivity for your network.
With a frequency of 100MHz, this cable provides outstanding
performance and speed. Its yellow jacket color allows for easy
identification, and the PVC jacket material guarantees durability
and long - term use. The cable length of 500 feet (converted to
approximately 152.4m) makes it ideal for large - scale networks and
long - distance connections.
Whether you're establishing a new network or upgrading your current
one, this Cable is the perfect choice to meet all your networking
requirements. Get this cable today and relish fast and reliable
connectivity!
| Product Name | Cat5e SFTP 24AWG Copper 500Ft Yellow PVC Jacket Shielded Ethernet Cable |
| Cable Type | CAT5E |
| Cable Length | 500FT |
| Conductor Gauge | 24 AWG |
| Conductor Material | Copper |
| Cable Shielding | SFTP |
| Jacket Material | PVC |
| Jacket Color | Yellow |
| Frequency | 100MHz |
Product Description: Cat5e SFTP 24AWG Copper 500Ft Yellow PVC Jacket Shielded Ethernet Cable | ||||||
| Rev.: A | ECN Description: | |||||
| Construction Item Description | Electrical Property | |||||
Conductor | Material | Bare Solid Copper(elongation: 19 ~ 24%) | Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m | ||
| OD | 24 AWG | Resistance unbalance within a pair | ≤ 2% | |||
Insulation | Material | HDPE 8303 | Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | >1500 MΩ / 100m | ||
| OD | 0.90 ± 0.02 mm | Mutual capacitance | 5600 pF / 100m MAX | |||
| Average THK | 0.20 mm | Capacitance unbalance pair to ground at 800Hz or 1 kHz | ≤ 160 pF / 100m | |||
Color | 1p: white + 2 blue stripes & blue | Characteristic impedance at 100MHz | 100 ± 15 Ω | |||
| 2p: white + 2 orange stripes & orange | Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | No breakdown | ||||
| 3p: white + 2 green stripes & green | Mechanical Property | |||||
| 4p: white + 2 brown stripes & brown | insulation | elongation before aging | ≥ 300% | |||
Pair Twist | Lay & Direction | 1p: S=20.0 mm (28%) | tensile strength before aging | ≥12 MPa | ||
| 2p: S=17.5 mm (24%)) | elongation after aging | ≥ 150 % | ||||
| 3p: S=22.0 mm (32%) | tensile strength after aging | ≥10.5 MPa | ||||
| 4p: S=15.5 mm (21%) | jacket | elongation before aging | ≥ 150 % | |||
| OD | / | tensile strength before aging | ≥ 13.5 MPa | |||
Inner Assemble | Lay | S=90 ± 5 mm | elongation after aging | ≥ 125 % | ||
| Direction | according to the drawing | tensile strength after aging | ≥ 12.5 MPa | |||
| Filler | / | Packing | ||||
| OD | / | Drum | NA | |||
| Filler | Ripcord | 300D | Master Carton | NA | ||
| Drain Wire | Tinned Copper | |||||
Outside Shield | Shield | Shield | ||||
| Construction | / | |||||
| Material | Polyester film/Aluminium Foil (PET/ALU) | |||||
| Coverage | ≥ 115% | |||||
Jacket | Material | PVC, 50P, -20~75℃ | ||||
| Hardness | 81 ± 3 | |||||
| OD | 6.5 ± 0.2 | |||||
| Average THK | 0.50 ~ 0.60 | |||||
Color | yellow | |||||
| Marking Color | black | |||||
| Marking | according to the customer's requirements | |||||
| Electrical Properties | ||
| Conductor Resistance at 20°C | NF EN 50289-1-2 / IEC 60189-1 | ≤ 9.5 Ω / 100m |
| Resistance unbalance within a pair | NF EN 50289-1-2/ IEC 60708 | ≤ 2% |
Dielectric Strength Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | NF EN 50289-1-3 / IEC 61196-1-105 | No breakdown |
| Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | NF EN 50289-1-4 / IEC 60885-1 | >1500 MΩ / 100m |
| Mutual capacitance | NF EN 50289-1-5 /IEC 60189-1 | 5600pF / 100m MAX |
| Capacitance unbalance pair to ground at 800Hz or 1 kHz | NF EN 50289-1-5 / IEC 60189-1 | ≤ 160 pF / 100m |
| Characteristic impedance at 100MHz | NF EN 50289-1-11/ IEC 61156-1 | 100 ± 15 Ω |
| Spark Test | UL444 | 2000 ± 250VOC |
| Transmission Properties | |||||||||
| CAT5e ANSI/TIA-568.2-D; IEC 61156-6; YD/T1019-2013 | |||||||||
No. | Frequency | Attenuation (Max) | Propagation Delay (MAX) | Propagation Delay Skew (MAX) | Return Loss (Min) | NEXT (Min) | PS NEXT (Min) | EL-FEXT (Min) | PS EL-FEXT (Min) |
| MHz | dB/100m | ns/100m | ns/100m | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | |
| 1 | 4 | 4.05 | 552 | 45 | 23.01 | 56.27 | 53.27 | 51.96 | 48.96 |
| 2 | 8 | 5.77 | 546.73 | 45 | 24.52 | 51.75 | 48.75 | 45.94 | 42.94 |
| 3 | 10 | 6.47 | 545.38 | 45 | 25 | 50.3 | 47.3 | 44 | 41 |
| 4 | 16 | 8.25 | 543 | 45 | 25 | 47.24 | 44.24 | 39.92 | 36.92 |
| 5 | 20 | 9.27 | 542.05 | 45 | 25 | 45.78 | 42.78 | 37.98 | 34.98 |
| 6 | 25 | 10.42 | 541.2 | 45 | 24.32 | 44.33 | 41.33 | 36.04 | 33.04 |
| 7 | 31.25 | 11.72 | 540.44 | 45 | 23.64 | 42.88 | 39.88 | 34.1 | 31.1 |
| 8 | 50 | 15.07 | 539.09 | 45 | 22.21 | 39.82 | 36.82 | 30.02 | 27.02 |
| 9 | 62.5 | 16.99 | 538.55 | 45 | 21.54 | 38.36 | 35.36 | 28.08 | 25.08 |
| 10 | 100 | 21.98 | 537.6 | 45 | 20.11 | 35.3 | 32.3 | 24 | 21 |
| 11 | |||||||||
| 12 | |||||||||
| 13 | |||||||||
| 14 | |||||||||
| Remarks: ＊ are the reference values | |||||||||
1.The ITI-LINK ITI-CT5SF-017 SFTP Cat5e Ethernet Network Cable is designed to provide reliable and fast data transfer rates. It is ideal for use in small to medium-sized businesses that require a reliable and efficient local area network. The cable is also suitable for use in homes, schools, and other similar environments.
2.The yellow jacket color of the ITI-LINK ITI-CT5SF-017 SFTP Cat5e Ethernet Network Cable makes it easy to identify and distinguish from other cables. The cable is also made of high-quality materials, including copper conductor and PVC jacket material, which ensures that it is durable and long-lasting.
3.The ITI-LINK ITI-CT5SF-017 SFTP Cat5e Ethernet Network Cable is suitable for a wide range of applications and scenarios. It is perfect for use in office environments, data centers, and server rooms. It is also suitable for use in homes and small businesses that require high-speed internet connectivity.
4.The ITI-LINK ITI-CT5SF-017 SFTP Cat5e Ethernet Network Cable is an excellent choice for anyone looking for a reliable and efficient cable for their network. Whether you are setting up a new network or upgrading an existing one, this cable is sure to meet your needs.
In conclusion, the ITI-LINK ITI-CT5SF-017 SFTP Cat5e Ethernet Network Cable is a high-quality cable that offers reliable and fast data transfer rates. It is suitable for a wide range of applications and scenarios and is made of high-quality materials that ensure its durability and long-lasting performance.
Product Packaging and Shipping for SFTP CAT5E CABLE:
The SFTP CAT5E CABLE comes in a standard packaging box that measures approximately 28cm in length, 28cm in width, and 12cm in height.
For shipping, the product is shipped through standard shipping. The estimated delivery time is 15-45 business days. Expedited shipping options are available for an additional cost.
Customers can track their shipment using the tracking number provided by the seller. If there are any issues with the shipment, customers can contact the seller for assistance.
Q: What is the brand name of this SFTP CAT5E cable?
A: The brand name of this cable is ITI-LINK.
Q: What is the model number of this SFTP CAT5E cable?
A: The model number of this cable is ITI-CT5SF-017.
Q: Where is this SFTP CAT5E cable manufactured?
A: This cable is manufactured in SHENZHEN.
Q: How long is this SFTP CAT5E cable?
A: The length of this cable varies. Please refer to the product description for more information.
Q: What is the use of this SFTP CAT5E cable?
A: This cable is commonly used for networking, data transfer, and internet connections.
Q: Do you offer guarantee for the products?
A: Yes, we offer 10 years warranty to our products.
Q8: How to deal with the faulty?
Our products undergo strict testing upon leaving the factory to
ensure 100% compliance.
If there are any problems during transportation or other reasons
causing product issues, we will also do our best to help customers
solve them.
|
|
