| Brand Name : | ITI-LINK |
| Model Number : | ITI-CT5SF-020 |
| Certification : | UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS |
| Delivery Time : | 15-45Days |
| Payment Terms : | T/T |
| Supply Ability : | 2000pcs/day |
1.With a jacket color of gray and made of LSZH (Low Smoke Zero Halogen) material, this Cat5e SFTP 1000Feet Length Ethernet Cable is easy to identify and install. The LSZH jacket not only gives it a distinct appearance but also offers remarkable safety features. In case of a fire, it produces low smoke and no halogen gases, reducing the risk of toxic fume inhalation and damage to equipment.
2.This cable is constructed from high - quality copper conductors.
These conductors provide excellent conductivity, allowing for
smooth data transfer, and ensure durability over time. The copper
conductors are protected by a shielded twisted - pair (SFTP)
design. This design helps to minimize interference from external
electromagnetic sources and guarantees reliable data transfer,
making it ideal for applications that demand stable and high -
quality connections.
3.As a type of CAT5E cable, it is designed to support data transfer
rates of up to 1 Gbps. This enables it to handle a wide range of
applications with ease, such as streaming high - definition video,
online gaming without lag, and large - scale file transfers without
data loss.
4.With a length of 1000 feet, this cable provides extensive
flexibility for use in various settings. Whether you are setting up
a network in a small office, a large data center, or even an
industrial environment, the ample length ensures that you have
enough cable to complete the connection tasks effectively.
5.The conductor gauge of this cable is 24 AWG, which is a standard
gauge for CAT5E cables. This gauge strikes a good balance between
conductivity and durability, making the cable an ideal choice for
long - term use, even in demanding conditions.
6.Overall, the Cat5e SFTP 1000Feet Length Ethernet Cable with LSZH
Jacket is an outstanding choice for anyone in need of a reliable
and high - quality data transfer cable. Whether you are a network
administrator responsible for complex network infrastructures or a
home user looking for a stable connection for entertainment and
work purposes, this cable provides the speed, reliability, and
safety you require. So don't hesitate. Order your Cat5e SFTP
1000Feet Length Ethernet Cable today!
| Cable Type | CAT5E |
| Cable Length | 1000ft |
| Cable Shielding | SFTP |
| Conductor Material | Copper |
| Conductor Gauge | 24 AWG |
| Jacket Color | Gray |
Product Description: Cat5e SFTP LSZH Jacket 24AWG 100MHz Gray Ethernet Cable 1000FT | ||||||
| Rev.: A | ECN Description: | |||||
| Construction Item Description | Electrical Property | |||||
Conductor | Material | Bare Solid Copper(elongation: 19 ~ 24%) | Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m | ||
| OD | 24 AWG | Resistance unbalance within a pair | ≤ 2% | |||
Insulation | Material | HDPE 8303 | Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | >1500 MΩ / 100m | ||
| OD | 1.05 ± 0.02 mm | Mutual capacitance | 5600 pF / 100m MAX | |||
| Average THK | 0.24 mm | Capacitance unbalance pair to ground at 800Hz or 1 kHz | ≤ 160 pF / 100m | |||
Color | 1p: white + 2 blue stripes & blue | Characteristic impedance at 100MHz | 100 ± 15 Ω | |||
| 2p: white + 2 orange stripes & orange | Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | No breakdown | ||||
| 3p: white + 2 green stripes & green | Mechanical Property | |||||
| 4p: white + 2 brown stripes & brown | insulation | elongation before aging | ≥ 300% | |||
Pair Twist | Lay & Direction | 1p: S=20.0 mm (28%) | tensile strength before aging | ≥12 MPa | ||
| 2p: S=17.5 mm (24%)) | elongation after aging | ≥ 150 % | ||||
| 3p: S=22.0 mm (32%) | tensile strength after aging | ≥10.5 MPa | ||||
| 4p: S=15.5 mm (21%) | jacket | elongation before aging | ≥ 150 % | |||
| OD | / | tensile strength before aging | ≥ 13.5 MPa | |||
Inner Assemble | Lay | S=90 ± 5 mm | elongation after aging | ≥ 125 % | ||
| Direction | according to the drawing | tensile strength after aging | ≥ 12.5 MPa | |||
| Filler | / | Packing | ||||
| OD | / | Drum | NA | |||
| Filler | Ripcord | 300D | Master Carton | NA | ||
| Drain Wire | Tinned Copper | |||||
Outside Shield | Shield | Shield | ||||
| Construction | / | |||||
| Material | Polyester film/Aluminium Foil (PET/ALU) | |||||
| Coverage | ≥ 115% | |||||
Jacket | Material | LSZH, 60P, -20~75℃ | ||||
| Hardness | 81 ± 3 | |||||
| OD | 6.5 ± 0.2 | |||||
| Average THK | 0.50 ~ 0.60 | |||||
Color | Gray | |||||
| Marking Color | according to the customer's requirements | |||||
| Marking | according to the customer's requirements | |||||
| Electrical Properties | ||
| Conductor Resistance at 20°C | NF EN 50289-1-2 / IEC 60189-1 | ≤ 9.5 Ω / 100m |
| Resistance unbalance within a pair | NF EN 50289-1-2/ IEC 60708 | ≤ 2% |
Dielectric Strength Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | NF EN 50289-1-3 / IEC 61196-1-105 | No breakdown |
| Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | NF EN 50289-1-4 / IEC 60885-1 | >1500 MΩ / 100m |
| Mutual capacitance | NF EN 50289-1-5 /IEC 60189-1 | 5600pF / 100m MAX |
| Capacitance unbalance pair to ground at 800Hz or 1 kHz | NF EN 50289-1-5 / IEC 60189-1 | ≤ 160 pF / 100m |
| Characteristic impedance at 100MHz | NF EN 50289-1-11/ IEC 61156-1 | 100 ± 15 Ω |
| Spark Test | UL444 | 2000 ± 250VOC |
| Transmission Properties | |||||||||
| CAT5e ANSI/TIA-568.2-D; IEC 61156-6; YD/T1019-2013 | |||||||||
No. | Frequency | Attenuation (Max) | Propagation Delay (MAX) | Propagation Delay Skew (MAX) | Return Loss (Min) | NEXT (Min) | PS NEXT (Min) | EL-FEXT (Min) | PS EL-FEXT (Min) |
| MHz | dB/100m | ns/100m | ns/100m | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | |
| 1 | 4 | 4.05 | 552 | 45 | 23.01 | 56.27 | 53.27 | 51.96 | 48.96 |
| 2 | 8 | 5.77 | 546.73 | 45 | 24.52 | 51.75 | 48.75 | 45.94 | 42.94 |
| 3 | 10 | 6.47 | 545.38 | 45 | 25 | 50.3 | 47.3 | 44 | 41 |
| 4 | 16 | 8.25 | 543 | 45 | 25 | 47.24 | 44.24 | 39.92 | 36.92 |
| 5 | 20 | 9.27 | 542.05 | 45 | 25 | 45.78 | 42.78 | 37.98 | 34.98 |
| 6 | 25 | 10.42 | 541.2 | 45 | 24.32 | 44.33 | 41.33 | 36.04 | 33.04 |
| 7 | 31.25 | 11.72 | 540.44 | 45 | 23.64 | 42.88 | 39.88 | 34.1 | 31.1 |
| 8 | 50 | 15.07 | 539.09 | 45 | 22.21 | 39.82 | 36.82 | 30.02 | 27.02 |
| 9 | 62.5 | 16.99 | 538.55 | 45 | 21.54 | 38.36 | 35.36 | 28.08 | 25.08 |
| 10 | 100 | 21.98 | 537.6 | 45 | 20.11 | 35.3 | 32.3 | 24 | 21 |
| 11 | |||||||||
| 12 | |||||||||
| 13 | |||||||||
| 14 | |||||||||
| Remarks: ＊ are the reference values | |||||||||
1.This Cat5e SFTP 1000Feet Length Ethernet Cable with LSZH Jacket is perfect for a variety of applications, such as data centers, server rooms, and other high - performance networking environments. With a frequency of 100MHz, this cable is capable of supporting high - speed data transfer rates of up to 1Gbps, making it ideal for demanding applications that require fast and reliable data transfer.
2.One of the key benefits of this cable is its SFTP shielding. The
SFTP shielding provides superior protection against electromagnetic
interference and radio frequency interference. This ensures that
data is transmitted without errors, even in noisy environments.
Additionally, the blue LSZH jacket color makes it easy to identify
and trace in crowded cable bundles.
3.What's more, the LSZH jacket is a remarkable feature. In the
event of a fire, this cable will produce little to no smoke and no
halogen gases. This is of great significance in environments where
fire safety is crucial, like office buildings, data centers, and
industrial facilities. It not only protects the health of people
nearby by reducing the risk of inhaling toxic fumes but also
safeguards the delicate electronic equipment from potential damage
caused by corrosive halogen - related by - products.
4.This cable is suitable for a wide range of scenarios, including
office networks, home networks, and industrial environments. It can
be used to connect computers, printers, servers, routers, switches,
and other network devices. With its high - quality construction and
reliable performance, this cable is an excellent choice for any
data transfer application that requires high - speed and reliable
connectivity.
5.In summary, this cable that is perfect for a variety of
applications, including data centers, server rooms, and other high
- performance networking environments. Its SFTP shielding provides
superior protection against interference and noise, ensuring that
data is transmitted without errors. Whether you need to connect
computers, printers, servers, routers, switches, or other network
devices, this cable is an excellent choice for any data transfer
application that requires high - speed and reliable connectivity,
especially considering its added safety feature of the LSZH jacket.
Q: What is the brand name of this SFTP CAT5E cable?
A: The brand name of this cable is ITI-LINK.
Q: What is the model number of this SFTP CAT5E cable?
A: The model number of this cable is ITI-CT5SF-020.
Q: Where is this SFTP CAT5E cable manufactured?
A: This cable is manufactured in SHENZHEN.
Q: What is the maximum frequency this SFTP CAT5E cable can support?
A: This cable can support a maximum frequency of 100 MHz.
Q: What is the maximum length of this SFTP CAT5E cable?
A: The maximum length of this cable is 305 meters.
|
|
