| Brand Name : | ITI-LINK |
| Model Number : | ITI-CT5F-003 |
| Certification : | UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS |
| Payment Terms : | T/T |
| Supply Ability : | 2000pcs/day |
| Delivery Time : | 15-45Days |
1.The PE jacket material used in the construction of this FTP CAT5E Internet Cable makes it durable and long-lasting, ensuring that it can withstand the rigors of regular use. Additionally, this jacket material is resistant to abrasion and other forms of damage, making it ideal for installations in areas where the cable may be exposed to harsh conditions.
2.This cable is certified by UL, ETL, and RoHS, ensuring that it meets the highest standards for safety and performance. These certifications are an indication of the quality of this FTP CAT5E Data Cable and provide peace of mind to users that it will perform reliably and safely for years to come.
3.Shielded Category 5e twisted pair outdoor cables are applicable to outdoor network cabling scenarios, such as connecting network devices between buildings in a campus, transmitting data for outdoor surveillance systems, and providing stable network connections in the deployment of outdoor Wi-Fi hotspots, so as to resist external electromagnetic interference and ensure the stable and high-speed transmission of data.
4.The conductor size used in this FTP CAT5E Internet Cable is 24 AWG, which is the standard size for Ethernet cables of this type. This conductor size ensures that data is transmitted quickly and efficiently, with minimal loss or interference.
5.In summary, the FTP CAT5E Data Cable is a high-quality, reliable Ethernet cable that is ideal for use in a variety of networking applications. With its durable PE jacket, UL, ETL, and RoHS certifications, and superior performance capabilities, this FTP CAT5E Ethernet Patch Cable is a great choice for anyone looking for a high-performance Internet cable.
| Certifications: | UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS |
| Frequency: | 100MHz |
| Conductor Size: | 24 AWG |
| Conductor Material: | Copper |
| Jacket Material: | PE |
| Length: | 1000Ft |
| Cable Type: | FTP CAT5E OUTDOOR Cable |
| Color: | BLACK |
| Product Description: CAT5E F/UTP 24AWG Solid Outdoor PE Cable | ||||||
| Rev.: A | ECN Description: | |||||
| Construction Item Description | Electrical Property | |||||
Conductor | Material | Bare Solid Copper(elongation: 19 ~ 24%) | Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m | ||
| OD | 24 AWG | Resistance unbalance within a pair | ≤ 2% | |||
Insulation | Material | HDPE 8303 | Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | >1500 MΩ / 100m | ||
| OD | 0.88 ± 0.05 mm | Mutual capacitance | 5600 pF / 100m MAX | |||
| Average THK | 0.21 mm | Capacitance unbalance pair to ground at 800Hz or 1 kHz | ≤ 160 pF / 100m | |||
Color | 1p: white + 2 blue stripes & blue | Characteristic impedance at 100MHz | 100 ± 15 Ω | |||
2p: white + 2 orange stripes & orange | Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | No breakdown | ||||
| 3p: white + 2 green stripes & green | Mechanical Property | |||||
| 4p: white + 2 brown stripes & brown | insulation | elongation before aging | ≥ 300% | |||
Pair Twist | Lay & Direction | 1p: S=20.0 mm (28%) | tensile strength before aging | ≥16 MPa | ||
| 2p: S=17.5 mm (24%)) | elongation after aging | NA | ||||
| 3p: S=22.0 mm (32%) | tensile strength after aging | NA | ||||
| 4p: S=15.5 mm (21%) | jacket | elongation before aging | ≥350% | |||
| OD | / | tensile strength before aging | ≥9.7MPa | |||
Inner Assemble | Lay | S=90 ± 5 mm | elongation after aging | ≥263% | ||
| Direction | according to the drawing | tensile strength after aging | ≥7.3MPa | |||
| Filler | / | Packing | ||||
| OD | / | Inner Box | NA | |||
| Filler | Material | Ripcord | Master Carton | NA | ||
| Construction | 250D*3 | |||||
Outside Shield | Shield | Shield | ||||
| Construction | / | |||||
| Material | Polyester/Aluminium (PET/ALU) | |||||
| Coverage | ≥ 115% | |||||
Jacket | Material | Jacket: PE | ||||
| Hardness | 30 | |||||
| OD | 5.2 ± 0.2 | |||||
| Average THK | 0.45 ~ 0.55 | |||||
Color | Orange | |||||
Marking Color | according to the customer's requirements | |||||
| Marking | according to the customer's requirements | |||||
| Electrical Properties | ||
| Conductor Resistance at 20°C | UL 444 & CSA C22.2 No. 214 | ≤ 9.5 Ω / 100m |
| Resistance unbalance within a pair | ≤ 2% | |
Dielectric Strength Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | No breakdown | |
| Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | >1500 MΩ / 100m | |
| Mutual capacitance | 5600pF / 100m MAX | |
| Capacitance unbalance pair to ground at 800Hz or 1 kHz | ≤ 160 pF / 100m | |
| Characteristic impedance at 100MHz | 100 ± 15 Ω | |
| Spark Test | 2000 ± 250VOC | |
| Transmission Properties | |||||||||
| CAT5e F/UTP | |||||||||
No. | Frequency | Attenuation (Max) | Propagation Delay (MAX) | Propagation Delay Skew (MAX) | Return Loss (Min) | NEXT (Min) | PS NEXT (Min) | EL-FEXT (Min) | PS EL-FEXT (Min) |
| MHz | dB/100m | ns/100m | ns/100m | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | |
| 1 | 4 | 4.05 | 552 | 45 | 23.01 | 56.27 | 53.27 | 51.96 | 48.96 |
| 2 | 8 | 5.77 | 546.73 | 45 | 24.52 | 51.75 | 48.75 | 45.94 | 42.94 |
| 3 | 10 | 6.47 | 545.38 | 45 | 25 | 50.3 | 47.3 | 44 | 41 |
| 4 | 16 | 8.25 | 543 | 45 | 25 | 47.24 | 44.24 | 39.92 | 36.92 |
| 5 | 20 | 9.27 | 542.05 | 45 | 25 | 45.78 | 42.78 | 37.98 | 34.98 |
| 6 | 25 | 10.42 | 541.2 | 45 | 24.32 | 44.33 | 41.33 | 36.04 | 33.04 |
| 7 | 31.25 | 11.72 | 540.44 | 45 | 23.64 | 42.88 | 39.88 | 34.1 | 31.1 |
| 8 | 50 | 15.07 | 539.09 | 45 | 22.21 | 39.82 | 36.82 | 30.02 | 27.02 |
| 9 | 62.5 | 16.99 | 538.55 | 45 | 21.54 | 38.36 | 35.36 | 28.08 | 25.08 |
| 10 | 100 | 21.98 | 537.6 | 45 | 20.11 | 35.3 | 32.3 | 24 | 21 |
| 11 | |||||||||
| 12 | |||||||||
| 13 | |||||||||
| 14 | |||||||||
| Remarks: ＊ are the reference values | |||||||||
1.The ITI-CT5F-003 is a orange-colored cable that is perfect for both commercial and residential use. With a frequency of 100MHz, it can transmit data at high speeds, making it an ideal choice for large networks with heavy traffic. The length of the cable is 1000ft, providing ample length for most networking applications.
The cable type of ITI-CT5F-003 is FTP, which stands for Foiled Twisted Pair. This means that it has an additional layer of shielding around the twisted pairs of wires inside the cable. This shielding helps to reduce electromagnetic interference, making the cable less susceptible to noise and distortion. This makes it a reliable choice for data transmission in noisy environments.
The conductor size of ITI-CT5F-003 is 24 AWG, which is the standard size for CAT5E cables. This ensures that the cable can handle the data transfer speeds required for most networking applications. The cable is also designed to be flexible and durable, allowing for easy installation and long-term use.
The ITI-CT5F-003 FTP CAT5E LAN cable is ideal for a wide range of applications, including:
Whether you need to connect multiple devices or transfer large amounts of data, the ITI-CT5F-001 FTP CAT5E LAN cable is a reliable and efficient choice. It can also be used as an FTP CAT5E patch cord for shorter networking applications.
Q: What is the brand name of this FTP CAT5E cable?
A: The brand name of this cable is ITI-LINK.
Q: What is the model number for this cable?
A: The model number for this cable is ITI-CT5F-003.
Q: Where is this cable manufactured?
A: This cable is manufactured in Shenzhen, China.
Q: What is the maximum transmission speed for this cable?
A: This cable supports transmission speeds of up to 1Gbps.
Q: Is this cable suitable for outdoor use?
A: Yes. This is FTP OUTDOOR PE CAT5E CABLE.
Q. Do you have a minimum order quantity limit for network cable
orders?
A: Low MOQ, 1000PCS for sample checking is available.
Q. How do you ship the goods and how long does it take to arrive?
A: We usually ship by sea, which usually takes about 7 days to
arrive.
|
|
