| Brand Name : | ITI-LINK |
| Model Number : | ITI-CT6U-0011 |
| Certification : | UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS |
| Delivery Time : | 15-45Days |
| Supply Ability : | 2000pcs/day |
| Payment Terms : | T/T |
1.The jacket material of the UTP CAT6 CABLE is made of PVC, ensuring durability and protection against environmental factors. The cable is colored GREEN, making it easy to distinguish from other cables in an installation.
2. As a CAT6 network cable, the UTP CAT6 CABLE is compatible with a wide range of devices and applications that require fast and reliable network connectivity. It is capable of delivering up to 1Gbps of data transfer speed, making it an excellent choice for large file transfers and high-bandwidth applications.
3.The UTP CAT6 CABLE is designed to meet industry standards and specifications, ensuring that it will work seamlessly with other network components. It is also easy to install and configure, making it an ideal choice for both novice and experienced network administrators.
4. Overall, the UTP CAT6 CABLE is an excellent choice for anyone who needs to set up a fast and reliable network connection. With its high performance, durability, and compatibility with a wide range of devices and applications, it is a must-have for any network setup.
| Product Description: Cat 6 UTP 23AWG PVC Green Cable | ||||||
| Rev.: A | ECN Description: | |||||
| Construction Item Description | Electrical Property | |||||
Conductor | Material | Bare Solid Copper(elongation: 19-24%) | Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m | ||
| OD | 23 AWG | Resistance unbalance within a pair | ≤ 2% | |||
Insulation | Material | HDPE 8303 | Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | >1500 MΩ / 100m | ||
| OD | 1.01 ± 0.01 mm | Mutual capacitance | 5600 pF / 100m MAX | |||
| Average THK | 0.22 mm | Capacitance unbalance pair to ground at 800Hz or 1 kHz | ≤ 160 pF / 100m | |||
Color | 1p: white + 2 blue stripes & blue | Characteristic impedance at 100MHz | 100 ±15 Ω | |||
| 2p: white + 2 orange stripes & orange | Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | No breakdown | ||||
| 3p: white + 2 green stripes & green | Mechanical Property | |||||
| 4p: white + 2 brown stripes & brown | insulation | elongation before aging | ≥ 300% | |||
Pair Twist | Lay & Direction | 1p: S=18.5 mm (26%) | tensile strength before aging | ≥12 MPa | ||
| 2p: S=15.5 mm (21%) | elongation after aging | ≥ 150 % | ||||
| 3p: S=20.5 mm (30%) | tensile strength after aging | ≥10.5 MPa | ||||
| 4p: S=14.0 mm (19%) | jacket | elongation before aging | ≥ 150 % | |||
| OD | / | tensile strength before aging | ≥ 13.5 MPa | |||
Inner Assemble | Lay | S=90±5 mm | elongation after aging | ≥ 125 % | ||
| Direction | according to the drawing | tensile strength after aging | ≥ 12.5 MPa | |||
| Filler | cross member 4.8X4.8X0.5mmT | Packing | ||||
| OD | / | Inner Box | NA | |||
| Filler | Material | Ripcord | Master Carton | NA | ||
| Construction | 300D | |||||
Outside Shield | Shield | / | ||||
| Construction | / | |||||
| Material | / | |||||
| Coverage | / | |||||
Jacket | Material | PVC, 50P, -20~75℃ | ||||
| Hardness | 81 ±3 | |||||
| OD | 6.0 ± 0.15 | |||||
| Average THK | 0.55~0.60 | |||||
Color | GREEN | |||||
| Marking Color | BLACK | |||||
| Marking | according to the customer's requirements | |||||
| Electrical Properties | ||
| Conductor Resistance at 20°C | NF EN 50289-1-2 / IEC 60189-1 | ≤ 9.5 Ω / 100m |
| Resistance unbalance within a pair | NF EN 50289-1-2/ IEC 60708 | ≤ 2% |
Dielectric Strength Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | NF EN 50289-1-3 / IEC 61196-1-105 | No breakdown |
Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | NF EN 50289-1-4 / IEC 60885-1 | >1500 MΩ / 100m |
| Mutual capacitance | NF EN 50289-1-5 /IEC 60189-1 | 5600pF / 100m MAX |
| Capacitance unbalance pair to ground at 800Hz or 1 kHz | NF EN 50289-1-5 / IEC 60189-1 | ≤ 160 pF / 100m |
| Characteristic impedance at 100MHz | NF EN 50289-1-11/ IEC 61156-1 | 100 ± 15 Ω |
| Spark Test | UL444 | 2000 ± 250VOC |
| Transmission Properties | |||||||||
| CAT 6 ANSI/TIA-568.2-D; IEC 61156-6; YD/T1019-2013 | |||||||||
No. | Frequency | Attenuation (Max) | Propagation Delay (MAX) | Propagation Delay Skew (MAX) | Return Loss (Min) | NEXT (Min) | PS NEXT (Min) | EL-FEXT (Min) | PS EL-FEXT (Min) |
| MHz | dB/100m | ns/100m | ns/100m | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | |
| 1 | 4 | 3.78 | 552 | 45 | 23.01 | 66.27 | 63.27 | 55.96 | 52.96 |
| 2 | 8 | 5.32 | 546.73 | 45 | 24.52 | 61.75 | 58.75 | 49.94 | 46.94 |
| 3 | 10 | 5.95 | 545.38 | 45 | 25 | 60.3 | 57.3 | 48 | 45 |
| 4 | 16 | 7.55 | 543 | 45 | 25 | 57.24 | 54.24 | 43.92 | 40.92 |
| 5 | 20 | 8.47 | 542.05 | 45 | 25 | 55.78 | 52.78 | 41.98 | 38.98 |
| 6 | 25 | 9.51 | 541.2 | 45 | 24.32 | 54.33 | 51.33 | 40.04 | 37.04 |
| 7 | 31.25 | 10.67 | 540.44 | 45 | 23.64 | 52.88 | 49.88 | 38.1 | 35.1 |
| 8 | 50 | 13.66 | 539.09 | 45 | 22.21 | 49.82 | 46.82 | 34.02 | 31.02 |
| 9 | 62.5 | 15.38 | 538.55 | 45 | 21.54 | 48.36 | 45.36 | 32.08 | 29.08 |
| 10 | 100 | 19.8 | 537.6 | 45 | 20.11 | 45.3 | 42.3 | 28 | 25 |
| 11 | 125 | 22.36 | 537.22 | 45 | 19.43 | 43.85 | 40.85 | 26.06 | 23.06 |
| 12 | 200 | 28.98 | 536.55 | 45 | 18 | 40.78 | 37.78 | 21.98 | 18.98 |
| 13 | 250 | 32.85 | 536.28 | 45 | 17.32 | 39.33 | 36.33 | 20.04 | 17.04 |
| 14 | |||||||||
| 15 | |||||||||
| 16 | |||||||||
| 17 | |||||||||
| 18 | |||||||||
| Remarks: ＊ are the reference values. | |||||||||
1. With a conductor size of 23AWG, the ITI-LINK CAT6 cable is designed to deliver reliable performance for data transfer rates up to 1 Gbps. This makes it an ideal choice for a wide range of applications, including home and office networks, data centers, and server rooms.
2. The ITI-CT6U-0011 CAT6 network cable is unshielded, which means it is not encased in a protective layer. This makes it easier to install and more flexible than shielded cables. It is also available in blue, which makes it easy to identify and distinguish from other cables in your network.
3. Whether you are setting up a new network or upgrading an existing one, the ITI-LINK CAT6 cable is a reliable and cost-effective solution. It is compatible with Ethernet networks and meets the CAT6 standard, which ensures reliable performance and compatibility with other CAT6 devices.
4. ITI-LINK's CAT6 UTP Cable is available for purchase in quantities of 1000 or more. The cable is packaged in a box with dimensions of 40X40X22CM and is able to be delivered within 15 days of the order. With a supply ability of 1500PCS/DAY, ITI-LINK is able to accommodate large orders in a timely manner.
5.Whether you are a small business owner or a network administrator at a large corporation, the ITI-LINK CAT6 cable is an essential component for building and maintaining a reliable network. Order now to experience the benefits of this high-quality CAT6 network cable.
Q: What is the brand name of this UTP CAT6 cable?
A: The brand name of this UTP CAT6 cable is ITI-LINK.
Q: What is the model number of this UTP CAT6 cable?
A: The model number of this UTP CAT6 cable is ITI-CT6U-0011.
Q: Where is this UTP CAT6 cable manufactured?
A: This UTP CAT6 cable is manufactured in SHENZHEN.
Q: What certifications does this UTP CAT6 cable have?
A: This UTP CAT6 cable has certifications including UL, ETL, CSA, RCM, TUV, CPR, CE, and RoHS.
Q: What is the minimum order quantity for this UTP CAT6 cable?
A: The minimum order quantity for this UTP CAT6 cable is 1000PCS.
Q: What are the packaging details for this UTP CAT6 cable?
A: The packaging details for this UTP CAT6 cable are 40X40X22CM.
Q: What is the delivery time for this UTP CAT6 cable?
A: The delivery time for this UTP CAT6 cable is 15DAYS.
Q: What is the supply ability of this UTP CAT6 cable per day?
A: The supply ability of this UTP CAT6 cable per day is 1500PCS/DAY.
|
|
