High quality cable manufacturer！ 5G communication cable | EV Cable
2 Years
| Ask Lasest Price | |
| Brand Name : | ITI-LINK |
| Model Number : | ITI-CT6U-0017 |
| Certification : | UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS |
| Delivery Time : | 15-45Days |
| Supply Ability : | 2000pcs/day |
| Payment Terms : | T/T |
1. One of the key features of the UTP CAT6 CABLE is its certifications. This cable has been certified by UL, CSA, ETL, CPR, TUV, RCM, CE, and RoHS, ensuring that it meets the highest standards of quality and safety. These certifications mean that you can trust this cable to provide reliable and consistent performance, even in demanding environments.
2. The UTP CAT6 CABLE is part of the CAT6 family of cables, which are designed for use in high-speed networks. These cables are compatible with all CAT6 equipment, making them an ideal choice for network administrators who need to upgrade their infrastructure. Whether you're building a new network or upgrading an existing one, the UTP CAT6 CABLE is a great choice.
3. One of the key advantages of the UTP CAT6 CABLE is its conductor size. This cable features 23AWG conductors, which are larger than those found in many other CAT6 cables. This means that the UTP CAT6 CABLE can provide better signal quality and lower attenuation, resulting in faster and more reliable data transmission.
4. In summary, the UTP CAT6 CABLE is a high-quality CAT6 NETWORK CABLE that is ideal for high-speed networks. With a bandwidth of 250MHz, certifications from UL, CSA, ETL, CPR, TUV, RCM, CE, and RoHS, and a conductor size of 23AWG, this CAT 6 CABLE is capable of transmitting data at speeds of up to 1Gbps, making it perfect for high-speed internet connections, video streaming, and other bandwidth-intensive applications.
5. We conduct strict quality inspections on every product to ensure a 99.9% pass rate.
| Compatibility | Ethernet |
| Category | CAT6 LAN CABLE |
| Shielding | Unshielded |
| Certifications | UL, CSA, ETL, CPR, TUV, RCM, CE, RoHS |
| Transmission Speed | 1Gbps |
| Bandwidth | 250MHz |
| Jacket Material | PVC |
| Length | 500ft |
| Color | Blue |
| Conductor Size | 23AWG |
Specifications:
| Product Description: CAT6 UTP 23AWG Solid Blue PVC Cable 500ft | ||||||
| Rev.: A | ECN Description: | |||||
| Construction Item Description | Electrical Property | |||||
Conductor | Material | Bare Solid Copper(elongation: 19 ~ 24%) | Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m | ||
| OD | 23 AWG | Resistance unbalance within a pair | ≤ 2% | |||
Insulation | Material | HDPE 8303 | Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | >1500 MΩ / 100m | ||
| OD | 1.14 ± 0.05 mm | Mutual capacitance | 5600 pF / 100m MAX | |||
| Average THK | 0.29 mm | Capacitance unbalance pair to ground at 800Hz or 1 kHz | ≤ 160 pF / 100m | |||
Color | 1p: white + 2 blue stripes & blue | Characteristic impedance at 100MHz | 100 ± 15 Ω | |||
2p: white + 2 orange stripes & orange | Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | No breakdown | ||||
| 3p: white + 2 green stripes & green | Mechanical Property | |||||
| 4p: white + 2 brown stripes & brown | insulation | elongation before aging | ≥ 300% | |||
Pair Twist | Lay & Direction | 1p: S=20.0 mm (28%) | tensile strength before aging | ≥16 MPa | ||
| 2p: S=17.5 mm (24%)) | elongation after aging | ≥ 150 % | ||||
| 3p: S=22.0 mm (32%) | tensile strength after aging | ≥10.5 MPa | ||||
| 4p: S=15.5 mm (21%) | jacket | elongation before aging | ≥350% | |||
| OD | / | tensile strength before aging | ≥9.7MPa | |||
Inner Assemble | Lay | S=90 ± 5 mm | elongation after aging | ≥263% | ||
| Direction | according to the drawing | tensile strength after aging | ≥7.3MPa | |||
| Filler | / | Packing | ||||
| OD | / | Inner Box | NA | |||
| Filler | Material | Ripcord | Master Carton | NA | ||
| Construction | 300D | |||||
Outside Shield | Shield | / | ||||
| Construction | / | |||||
| Material | / | |||||
| Coverage | / | |||||
Jacket | Material | Inner Jacket: PVC + Outside Jacket: PE | ||||
| Hardness | / | |||||
| OD | 5.8 / 7.2 | |||||
| Average THK | / | |||||
Color | blue | |||||
Marking Color | black | |||||
Marking | according to the customer's requirements | |||||
| Electrical Properties | ||
| Conductor Resistance at 20°C | UL 444 & CSA C22.2 No. 214 | ≤ 9.5 Ω / 100m |
| Resistance unbalance within a pair | ≤ 2% | |
Dielectric Strength Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | No breakdown | |
| Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | >1500 MΩ / 100m | |
| Mutual capacitance | 5600pF / 100m MAX | |
| Capacitance unbalance pair to ground at 800Hz or 1 kHz | ≤ 160 pF / 100m | |
| Characteristic impedance at 100MHz | 100 ± 15 Ω | |
| Spark Test | 2000 ± 250VOC | |
| Transmission Properties | |||||||||
| CAT 6 UTP Cable | |||||||||
No. | Frequency | Attenuation (Max) | Propagation Delay (MAX) | Propagation Delay Skew (MAX) | Return Loss (Min) | NEXT (Min) | PS NEXT (Min) | EL-FEXT (Min) | PS EL-FEXT (Min) |
| MHz | dB/100m | ns/100m | ns/100m | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | |
| 1 | 4 | 3.78 | 552 | 45 | 23.01 | 66.27 | 63.27 | 55.96 | 52.96 |
| 2 | 8 | 5.32 | 546.73 | 45 | 24.52 | 61.75 | 58.75 | 49.94 | 46.94 |
| 3 | 10 | 5.95 | 545.38 | 45 | 25 | 60.3 | 57.3 | 48 | 45 |
| 4 | 16 | 7.55 | 543 | 45 | 25 | 57.24 | 54.24 | 43.92 | 40.92 |
| 5 | 20 | 8.47 | 542.05 | 45 | 25 | 55.78 | 52.78 | 41.98 | 38.98 |
| 6 | 25 | 9.51 | 541.2 | 45 | 24.32 | 54.33 | 51.33 | 40.04 | 37.04 |
| 7 | 31.25 | 10.67 | 540.44 | 45 | 23.64 | 52.88 | 49.88 | 38.1 | 35.1 |
| 8 | 50 | 13.66 | 539.09 | 45 | 22.21 | 49.82 | 46.82 | 34.02 | 31.02 |
| 9 | 62.5 | 15.38 | 538.55 | 45 | 21.54 | 48.36 | 45.36 | 32.08 | 29.08 |
| 10 | 100 | 19.8 | 537.6 | 45 | 20.11 | 45.3 | 42.3 | 28 | 25 |
| 11 | 125 | 22.36 | 537.22 | 45 | 19.43 | 43.85 | 40.85 | 26.06 | 23.06 |
| 12 | 200 | 28.98 | 536.55 | 45 | 18 | 40.78 | 37.78 | 21.98 | 18.98 |
| 13 | 250 | 32.85 | 536.28 | 45 | 17.32 | 39.33 | 36.33 | 20.04 | 17.04 |
| 14 | |||||||||
| 15 | |||||||||
| 16 | |||||||||
| 17 | |||||||||
| 18 | |||||||||
| Remarks: ＊ are the reference values. | |||||||||
The UTP CAT6 CABLE is a high-performance network cable that supports transmission speeds of up to 1Gbps. With its unshielded shielding, this cable is ideal for use in areas with low electromagnetic interference. The conductor size of this cable is 23AWG and is made of PVC jacket material.
The CAT6 UTP cable is perfect for a variety of applications and scenarios, such as:
With the ITI-CT6U-017 CAT6 CABLE, you can be confident in its ability to provide high-speed and reliable data transmission. Its certification ensures that it meets industry standards for safety and performance.
FAQ:
Q1: What is the brand name of this product?
A1: The brand name of this product is ITI-LINK.
Q2: What is the model number of this product?
A2: The model number of this product is ITI-CT6U-0017.
Q3: What is the place of origin of this product?
A3: The place of origin of this product is SHENZHEN.
Q4: What certifications does this product have?
A4: This product has UL, ETL, CSA, RCM, TUV, CPR, CE, and RoHS certifications.
Q5: What is the minimum order quantity for this product?
A5: The minimum order quantity for this product is 1000PCS.
Q6: What are the packaging details of this product?
A6: The packaging details of this product are 40X40X22CM.
Q7: What is the delivery time for this product?
A7: The delivery time for this product is 15DAYS.
Q8: What is the supply ability of this product?
A8: The supply ability of this product is 1500PCS/DAY.
|
|
