Orange Cat5e SFTP CAT 5E 1000FT LSZH 24AWG Ethernet Cable Expend To 350Hz

Ask Lasest Price
Brand Name :	ITI-LINK
Model Number :	ITI-CT5SF-004
Certification :	UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
Delivery Time :	15-45Days
Payment Terms :	T/T
Supply Ability :	2000pcs/day

Add to Cart

Product Details
Company Profile

Orange Cat5e SFTP CAT 5E 1000FT LSZH 24AWG Ethernet Cable Expend To 350Hz

Cat5e SFTP Orange LSZH 24AWG Ethernet Cable Expend to 350Hz 1000FT

Product Description:

1.The Cat5e SFTP 24AWG 1000Ft Orange LSZH Ethernet Cable is an outstanding choice for your networking needs. With a length of 1000 feet (equivalent to approximately 305 meters when converted), it provides you with ample cable to connect your devices, even in extensive and complex large - scale networks.

2.The cable features an SFTP shielding structure. This unique design incorporates both a foil shield and a braided shield. The combination of these two shielding elements significantly reduces electromagnetic interference. As a result, it establishes a more secure and stable connection environment, ensuring that your data transmission remains uninterrupted and reliable.

3.This Cat5e SFTP cable is especially ideal for users who require a fast and dependable connection for their various devices. The Low - Smoke Zero - Halogen (LSZH) jacket material, which is orange in color, not only offers excellent protection against potential damage but also makes the cable easy to handle during installation.

4.Whether you are in the process of setting up connections among numerous devices within a large - scale network infrastructure or simply need a cable for your personal computer at home or in the office, this Cat5e SFTP 24AWG 1000Ft Orange LSZH Ethernet Cable is the perfect fit. Moreover, its enhanced performance extends its usability up to 350Hz, making it suitable for a wide range of applications that demand higher frequency support.

Technical Parameters:

Product Attribute	Value
Cable Type	CAT5E
Cable Length	1000FT
Cable Shielding	SFTP
Conductor Gauge	24 AWG
Conductor Material	Copper
Frequency	100MHz
Jacket Material	LSZH
Jacket Color	Red

Product Description:

Cat5e SFTP 24AWG 1000Ft Orange LSZH Ethernet Cable Expend to 350Hz
Rev.: A		ECN Description:
Construction Item Description			Electrical Property
Conductor	Material	Bare Solid Copper(elongation: 19 ~ 24%)	Conductor Resistance at 20°C			≤ 9.5 Ω / 100m
	OD	24 AWG	Resistance unbalance within a pair			≤ 2%
Insulation	Material	HDPE 8303	Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V			>1500 MΩ / 100m
	OD	1.05 ± 0.02 mm	Mutual capacitance			5600 pF / 100m MAX
	Average THK	0.24 mm	Capacitance unbalance pair to ground at 800Hz or 1 kHz			≤ 160 pF / 100m
	Color	1p: white + 2 blue stripes & blue	Characteristic impedance at 100MHz			100 ± 15 Ω
		2p: white + 2 orange stripes & orange	Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min			No breakdown
		3p: white + 2 green stripes & green	Mechanical Property
		4p: white + 2 brown stripes & brown	insulation	elongation before aging		≥ 300%
Pair Twist	Lay & Direction	1p: S=20.0 mm (28%)		tensile strength before aging		≥12 MPa
		2p: S=17.5 mm (24%))		elongation after aging		≥ 150 %
		3p: S=22.0 mm (32%)		tensile strength after aging		≥10.5 MPa
		4p: S=15.5 mm (21%)	jacket	elongation before aging		≥ 150 %
	OD	/		tensile strength before aging		≥ 13.5 MPa
Inner Assemble	Lay	S=90 ± 5 mm		elongation after aging		≥ 125 %
	Direction	according to the drawing		tensile strength after aging		≥ 12.5 MPa
	Filler	/	Packing
	OD	/	Drum		NA
Filler	Ripcord	300D	Master Carton		NA
	Drain Wire	Tinned Copper
Outside Shield	Shield	Shield
	Construction	/
	Material	Polyester film/Aluminium Foil (PET/ALU)
	Coverage	≥ 115%
Jacket	Material	LSZH, 60P, -20~75℃
	Hardness	81 ± 3
	OD	6.5 ± 0.2
	Average THK	0.50 ~ 0.60
	Color	Orange
	Marking Color	Black
Marking		according to the customer's requirements

Electrical Properties
Conductor Resistance at 20°C	NF EN 50289-1-2 / IEC 60189-1	≤ 9.5 Ω / 100m
Resistance unbalance within a pair	NF EN 50289-1-2/ IEC 60708	≤ 2%
Dielectric Strength Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min	NF EN 50289-1-3 / IEC 61196-1-105	No breakdown
Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V	NF EN 50289-1-4 / IEC 60885-1	>1500 MΩ / 100m
Mutual capacitance	NF EN 50289-1-5 /IEC 60189-1	5600pF / 100m MAX
Capacitance unbalance pair to ground at 800Hz or 1 kHz	NF EN 50289-1-5 / IEC 60189-1	≤ 160 pF / 100m
Characteristic impedance at 100MHz	NF EN 50289-1-11/ IEC 61156-1	100 ± 15 Ω
Spark Test	UL444	2000 ± 250VOC

Transmission Properties
CAT5e ANSI/TIA-568.2-D; IEC 61156-6; YD/T1019-2013
No.	Frequency	Attenuation (Max)	Propagation Delay (MAX)	Propagation Delay Skew (MAX)	Return Loss (Min)	NEXT (Min)	PS NEXT (Min)	EL-FEXT (Min)	PS EL-FEXT (Min)
No.	MHz	dB/100m	ns/100m	ns/100m	dB(on 100m)	dB(on 100m)	dB(on 100m)	dB(on 100m)	dB(on 100m)
1	4	4.05	552	45	23.01	56.27	53.27	51.96	48.96
2	8	5.77	546.73	45	24.52	51.75	48.75	45.94	42.94
3	10	6.47	545.38	45	25	50.3	47.3	44	41
4	16	8.25	543	45	25	47.24	44.24	39.92	36.92
5	20	9.27	542.05	45	25	45.78	42.78	37.98	34.98
6	25	10.42	541.2	45	24.32	44.33	41.33	36.04	33.04
7	31.25	11.72	540.44	45	23.64	42.88	39.88	34.1	31.1
8	50	15.07	539.09	45	22.21	39.82	36.82	30.02	27.02
9	62.5	16.99	538.55	45	21.54	38.36	35.36	28.08	25.08
10	100	21.98	537.6	45	20.11	35.3	32.3	24	21
11
12
13
14
Remarks: ＊ are the reference values

Applications:

1.The Cat5e SFTP 24AWG 1000Ft Orange LSZH Ethernet Cable, similar to the ITI - CT5SF - 004, is an outstanding cable for various networking requirements. It has a length of 1000Ft (equivalent to around 305m when converted), made from top - grade materials that guarantee its long - lasting durability and high reliability.

2.This cable consists of copper conductors with a 24 AWG gauge. These conductors are perfect for high - speed data transmission, enabling seamless and efficient data flow. The cable's outer jacket is made of Low - Smoke Zero - Halogen (LSZH) material in an orange color. This not only offers superb protection to the cable but also ensures that it can endure a diverse range of environmental conditions, including those where fire safety and low - smoke emissions are crucial.

3.The Cat5e SFTP Shielded Cable is engineered to provide exceptional shielding against electromagnetic interference. Electromagnetic interference can be a nightmare as it often leads to data errors and signal degradation. However, the shielding of this cable, crafted from premium materials, offers excellent protection against external interference sources, maintaining the integrity of the data signals.

The Cat5e SFTP 24AWG 1000Ft Orange LSZH Ethernet Cable is suitable for an extensive array of applications:

In small home networks, it can connect various devices such as computers, smart TVs, and gaming consoles, providing stable and fast connections for daily use.
For large enterprise networks, it can handle the complex data transmission demands between numerous offices, departments, and servers, ensuring smooth business operations.
In data centers, where vast amounts of data are constantly being processed and transferred, this cable can ensure the accuracy and speed of data transmission among racks of servers.
Server rooms rely on this cable to connect servers and networking equipment, maintaining stable communication channels for critical applications.
In telecommunications networks, it can be used for both short - distance connections within local exchanges and long - distance transmission in backbone networks, guaranteeing reliable signal transmission.
Even in industrial control systems, which are often exposed to harsh electromagnetic environments, this cable can provide stable connections for controlling machinery and monitoring processes.

Whether you need to transmit data over short distances within a single room or over long distances across different facilities, the Cat5e SFTP 24AWG 1000Ft Orange LSZH Ethernet Cable is the optimal choice. It provides remarkable signal integrity and robust protection against interference. Moreover, its performance can be extended to 350Hz, making it a highly reliable and versatile cable in the market, capable of meeting the demands of modern networking applications.

Orange Cat5e SFTP CAT 5E 1000FT LSZH 24AWG Ethernet Cable Expend To 350Hz

FAQ:

Q: What is the brand name of this SFTP CAT5E cable?

A: The brand name is ITI-LINK.

Q: What is the model number of this SFTP CAT5E cable?

A: The model number is ITI-CT5SF-004.

Q: Where is this SFTP CAT5E cable manufactured?

A: This cable is manufactured in SHENZHEN.

Q: What is the difference between SFTP and UTP CAT5E cables?

A: SFTP cables have an additional layer of shielding to reduce electromagnetic interference, while UTP cables do not have this extra layer.

Q: What is the maximum length of this SFTP CAT5E cable?

A: The maximum length of this cable is 1000Ft.
