| Brand Name : | ITI-LINK |
| Model Number : | ITI-CT6SF-003 |
| Certification : | UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS |
| Delivery Time : | 15-45 Days |
| Payment Terms : | T/T |
| Supply Ability : | 1500pcs/day |
1.The Cat6 SFTP 23AWG 250MHz LSZH Ethernet Blue Cable with 305 Meters Distance is designed with great precision to offer maximum protection against electromagnetic interference (EMI) and radio frequency interference (RFI), thereby ensuring the highest possible signal quality. The SFTP shielding type, which stands for shielded and foiled unshielded twisted pair, provides excellent protection. Compared to other cable types like UTP, it has distinct advantages. The Shielded Twisted Pair (STP) design within it effectively safeguards the conductors from external interference. Moreover, the foil shield offers an extra layer of defense against noise and interference, enabling stable and clear signal transmission.
2.The cable type of this product is CAT6, a well - known standard
Ethernet cable. It is capable of supporting high - speed data
transfer rates of up to 10Gbps, making it highly suitable for
handling large - volume data transmission without a hitch. The CAT6
cable is backward - compatible with CAT5 and CAT5e, which makes it
an ideal option for upgrading your existing network infrastructure.
With a maximum frequency of 250MHz, it can effortlessly manage high
- speed data transfer, ensuring seamless and efficient network
operations.
3.The conductor size of this cable is 23AWG, which adheres to the
standard for Ethernet cables. The conductor is crafted from high -
quality copper. This not only guarantees excellent signal quality
but also significantly reduces the risk of signal loss or
attenuation during transmission. Additionally, the copper conductor
is coated with a layer of high - quality insulation. This
insulation layer acts as an additional safeguard against electrical
interference, further enhancing the signal quality.
4.The jacket material of this cable is low - smoke, zero - halogen
(LSZH). This special LSZH material provides outstanding protection
against physical damage such as cuts and abrasions. It also offers
remarkable resistance to environmental factors including moisture,
heat, and cold. In the event of a fire, the LSZH material emits
very little smoke and no halogen gas, which is of great
significance for minimizing potential harm to people and equipment.
The blue color of the cable not only gives it an aesthetically
pleasing appearance but also makes it easily distinguishable during
installation and maintenance. This cable is suitable for use in a
wide variety of environments, both indoor and outdoor, making it an
ideal choice for both commercial and residential installations,
especially in areas where safety and environmental protection are
of high priority.
5.In conclusion, the Cat 6 Ethernet Blue Cable is a high -
performance cable that provides reliable network connectivity and
high - speed data transfer. This 305 - meter - long cable is
designed to endure the challenges of daily use. It offers maximum
shielding against EMI and RFI to ensure optimal signal quality,
while the LSZH jacket provides excellent protection against
physical damage and potential hazards during emergencies. Overall,
this cable is an outstanding choice for those in search of a high -
quality Ethernet cable that combines reliable performance, value
for money, and meets strict safety and environmental standards.
This Cat 6 Network Cable, also known as Cat6 SFTP Cables and Cat6 Lan Cable, is made with LSZH Jacket Material and Copper Conductor Material. It has a length of 305 Meters and a shielding type of SFTP. The cable has a maximum frequency of 250MHz and the conductor size is 23AWG. It is colored blue..
| Cable Type: | CAT6 LAN Cable / Cat6 SFTP Cable / Cat6 Cable |
| Conductor Size: | 23AWG |
| Jacket Material: | LSZH |
| Shielding Type: | SFTP |
| Conductor Material: | Copper |
| Maximum Transmission Distance: | 100 Meters |
| Maximum Frequency: | 250MHz |
| Color: | Blue |
Product Description: Cat6 SFTP LSZH 23AWG 250MHz Ethernet Blue Network Cable 1000FT | ||||||
| Rev.: A | ECN Description: | |||||
| Construction Item Description | Electrical Property | |||||
Conductor | Material | Bare Solid Copper(elongation: 19-24%) | Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m | ||
| OD | 23 AWG | Resistance unbalance within a pair | ≤ 2% | |||
Insulation | Material | HDPE | Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | >1500 MΩ / 100m | ||
| OD | 1.14 ±0.05 mm | Mutual capacitance | 5600 pF / 100m MAX | |||
| Average THK | 0.24 mm | Capacitance unbalance pair to ground at 800Hz or 1 kHz | ≤ 160 pF / 100m | |||
Color | 1p: white + 2 blue stripes & blue | Characteristic impedance at 100MHz | 100 ± 15 Ω | |||
| 2p: white + 2 orange stripes & orange | Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | No breakdown | ||||
| 3p: white + 2 green stripes & green | Mechanical Property | |||||
| 4p: white + 2 brown stripes & brown | insulation | elongation before aging | ≥ 300% | |||
Pair Twist | Lay & Direction | 1p: S=19.0 mm (27%) | tensile strength before aging | ≥12 MPa | ||
| 2p: S=23.5 mm (35%) | elongation after aging | ≥ 150 % | ||||
| 3p: S=21.5 mm (31%) | tensile strength after aging | ≥10.5 MPa | ||||
| 4p: S=27.0 mm (40%) | jacket | elongation before aging | ≥ 150 % | |||
| OD | / | tensile strength before aging | ≥ 13.5 MPa | |||
Inner Assemble | Lay | S=90 ± 5 mm | elongation after aging | ≥ 125 % | ||
| Direction | according to the drawing | tensile strength after aging | ≥ 12.5 MPa | |||
| Filler | cross member 5.0X5.0X0.5mmT | Packing | ||||
| OD | / | NA | NA | |||
| Filler | Ripcord | 300D | ||||
| Drain Wire | Tinned Copper | |||||
Shield | Shield | Shield | ||||
| Construction | / | |||||
| Material | Polyester/Aluminium (PET/ALU) | |||||
| Coverage | ≥ 115% | |||||
Jacket | Material | LSZH, 60P, -20~75℃ | ||||
| Hardness | 81± 3 | |||||
| OD | 7.2 ± 0.2 | |||||
| Average THK | 0.55 ~ 0.60 | |||||
Color | Blue | |||||
| Marking Color | according to the customer's requirements | |||||
| Marking | according to the customer's requirements | |||||
| Electrical Properties | ||
| Conductor Resistance at 20°C | NF EN 50289-1-2 / IEC 60189-1 | ≤ 9.5 Ω / 100m |
| Resistance unbalance within a pair | NF EN 50289-1-2/ IEC 60708 | ≤ 2% |
Dielectric Strength Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | NF EN 50289-1-3 / IEC 61196-1-105 | No breakdown |
| Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | NF EN 50289-1-4 / IEC 60885-1 | >1500 MΩ / 100m |
| Mutual capacitance | NF EN 50289-1-5 /IEC 60189-1 | 5600pF / 100m MAX |
| Capacitance unbalance pair to ground at 800Hz or 1 kHz | NF EN 50289-1-5 / IEC 60189-1 | ≤ 160 pF / 100m |
| Characteristic impedance at 100MHz | NF EN 50289-1-11/ IEC 61156-1 | 100 ± 15 Ω |
| Spark Test | UL444 | 2000 ± 250VOC |
| Transmission Properties | |||||||||
| CAT 6 ANSI/TIA-568.2-D; IEC 61156-6; YD/T1019-2013 | |||||||||
No. | Frequency | Attenuation (Max) | Propagation Delay (MAX) | Propagation Delay Skew (MAX) | Return Loss (Min) | NEXT (Min) | PS NEXT (Min) | EL-FEXT (Min) | PS EL-FEXT (Min) |
| MHz | dB/100m | ns/100m | ns/100m | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | |
| 1 | 4 | 3.78 | 552 | 45 | 23.01 | 66.27 | 63.27 | 55.96 | 52.96 |
| 2 | 8 | 5.32 | 546.73 | 45 | 24.52 | 61.75 | 58.75 | 49.94 | 46.94 |
| 3 | 10 | 5.95 | 545.38 | 45 | 25 | 60.3 | 57.3 | 48 | 45 |
| 4 | 16 | 7.55 | 543 | 45 | 25 | 57.24 | 54.24 | 43.92 | 40.92 |
| 5 | 20 | 8.47 | 542.05 | 45 | 25 | 55.78 | 52.78 | 41.98 | 38.98 |
| 6 | 25 | 9.51 | 541.2 | 45 | 24.32 | 54.33 | 51.33 | 40.04 | 37.04 |
| 7 | 31.25 | 10.67 | 540.44 | 45 | 23.64 | 52.88 | 49.88 | 38.1 | 35.1 |
| 8 | 50 | 13.66 | 539.09 | 45 | 22.21 | 49.82 | 46.82 | 34.02 | 31.02 |
| 9 | 62.5 | 15.38 | 538.55 | 45 | 21.54 | 48.36 | 45.36 | 32.08 | 29.08 |
| 10 | 100 | 19.8 | 537.6 | 45 | 20.11 | 45.3 | 42.3 | 28 | 25 |
| 11 | 125 | 22.36 | 537.22 | 45 | 19.43 | 43.85 | 40.85 | 26.06 | 23.06 |
| 12 | 200 | 28.98 | 536.55 | 45 | 18 | 40.78 | 37.78 | 21.98 | 18.98 |
| 13 | 250 | 32.85 | 536.28 | 45 | 17.32 | 39.33 | 36.33 | 20.04 | 17.04 |
| 14 | |||||||||
| 15 | |||||||||
| 16 | |||||||||
| 17 | |||||||||
| 18 | |||||||||
| Remarks: ＊ are the reference values. | |||||||||
1.The SFUTP shielding type of this Cat6 SFUTP 23AWG 250MHz LSZH Ethernet Blue Cable with 305 Meters Distance ensures that it is protected from electromagnetic interference, which can cause data loss or corruption. This shielding type also makes the cable resistant to crosstalk, which occurs when signals from one wire interfere with signals from another wire. With a maximum frequency of 250MHz, it has an advantage over most other networking cables in terms of frequency.
2.This cable is suitable for a wide variety of applications. It can
be used to connect computers, servers, switches, routers, and other
networking equipment. It is especially valuable in environments
where electromagnetic interference is a significant concern, such
as industrial settings with large - scale machinery or areas filled
with numerous electrical devices. In addition, in commercial
buildings like offices and data centers, where a large number of
cables are laid and interference might be an issue, this cable can
ensure stable data transmission.
3.For home networks, this cable is also excellent. It can be used
to connect gaming consoles for an immersive gaming experience
without lag caused by signal interference, media servers to stream
high - quality videos smoothly, and smart TVs for seamless
connectivity. Moreover, in public places like libraries, schools,
and hospitals, the low - smoke and zero - halogen (LSZH) feature of
this cable provides an extra level of safety. In the event of a
fire, the cable will not emit large amounts of toxic smoke or
halogen gases, minimizing potential harm to people and equipment.
The blue color of the cable also makes it easy to identify during
installation and maintenance in complex environments.
4.Overall, the Cat6 SFUTP 23AWG 250MHz LSZH Ethernet Blue Cable
with 305 Meters Distance is a high - quality networking cable that
is perfect for a broad range of applications. Its durable
construction, high data rate, SFUTP shielding, and LSZH material
make it an outstanding choice for anyone who needs a reliable,
fast, and safe networking cable.
Q: What is the brand name of this SFTP CAT6 cable?
A: The brand name of this cable is ITI-LINK.
Q: What is the model number of this cable?
A: The model number of this cable is ITI-CT6SF-003.
Q: Where is this cable manufactured?
A: This cable is manufactured in SHENZHEN.
Q: What is the maximum length available for this cable?
A: This cable is available in lengths up to 1000 feet.
Q: What is the maximum data transfer rate supported by this cable?
A: This cable supports data transfer rates of up to 10Gbps.
Q. Can I order samples of Lan cables?
A: Yes, we welcome sample order to test and check quality.
Q. What about the lead time?
A: Our factory takes 3-5 days to complete the sampling process,
while mass production takes 15-45 days to complete.
|
|
