| Brand Name : | ITI-LINK |
| Model Number : | ITI-CTSF7A-002 |
| Certification : | UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS |
| Delivery Time : | 15-45 Days |
| Payment Terms : | T/T |
| Supply Ability : | 2000pcs/day |
1.One of the key features of this CAT7A SFTP Cable with Shielded LSZH Jacket for High Speed Network Connections is its conductor size. It has a 23 AWG conductor, which means that it has a larger diameter than many other network cables. This makes it ideal for carrying data over long distances, such as in the case of its 1000Ft length, as it offers less resistance and can transmit data more efficiently. Additionally, the conductor material is made of copper, which is known for its excellent conductivity. This helps to ensure that data is transmitted accurately and quickly.
2.The SFTP shielding and LSZH jacket of this CAT7A cable are
significant. The SFTP feature provides enhanced protection against
electromagnetic interference, which is crucial for maintaining
stable network connections. The LSZH jacket not only offers safety
benefits by emitting low smoke and no toxic fumes in case of a fire
but also contributes to the cable's durability in various
environments.
3.This CAT7A cable is also designed to operate at high frequencies
of up to 1000 MHz, making it highly suitable for high-speed Network
Connections. This makes it ideal for use in environments where
there is a lot of network traffic, such as large offices or data
centers. With its high frequency rating, it can handle more data
traffic without slowing down or losing data.
4.The cable is colored yellow, which makes it easy to identify
among a mass of cables, facilitating installation and maintenance
work. It is made from high-quality materials that are designed to
withstand harsh environments and frequent use. The shielding helps
to prevent interference from other devices or cables. This helps to
ensure that data is transmitted accurately and reliably.
5.In summary, the CAT7A SFTP Cable with Shielded LSZH Jacket for
High Speed Network Connections is an excellent choice for those
looking for a high-quality network cable that is designed to offer
fast and reliable performance. Its yellow color makes it easy to
identify, and its 1000Ft length makes it suitable for large network
installations. With its 23 AWG conductor size, copper conductor
material, and high-frequency rating of up to 1000 MHz, it can
handle a large amount of data traffic without any issues. Its
durability, shielding, and LSZH jacket also make it an ideal choice
for use in harsh environments or areas with a lot of interference.
Overall, this CAT7A cable is a must-have for anyone looking to
create a reliable and fast network setup.
| Product Attribute | Value |
| Cable Type | SFTP |
| Cable Length | 1000Ft |
| Conductor Material | Copper |
| Conductor Size | 23 AWG |
| Jacket Material | LSZH |
| Category | CAT7A |
| Frequency | 1000MHz |
| Color | Yellow |
Product Description: CAT7A SFTP Cable with Shielded LSZH Jacket for High Speed Network Connections | ||||||
| Rev.: A | ECN Description: | |||||
| Construction Item Description | Electrical Property | |||||
Conductor | Material | Bare Solid Copper(elongation: 19-24%) | Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m | ||
| OD | 23AWG | Resistance unbalance within a pair | ≤ 2% | |||
Insulation | Material | PE Skin-Foam-Skin | Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | >1500 MΩ / 100m | ||
| OD | 1.45 ±0.01 mm | Mutual capacitance | 5600 pF / 100m MAX | |||
| Average THK | 0.42 mm | Capacitance unbalance pair to ground at 800Hz or 1 kHz | ≤ 160 pF / 100m | |||
Color | 1p: white + 2 blue stripes & blue | Characteristic impedance at 100MHz | 100 ± 15 Ω | |||
2p: white + 2 orange stripes & orange | Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | No breakdown | ||||
| 3p: white + 2 green stripes & green | Mechanical Property | |||||
| 4p: white + 2 brown stripes & brown | insulation | elongation before aging | ≥ 300% | |||
Pair Twist | Lay & Direction | 1p: S=19.0 mm (28%) | tensile strength before aging | ≥12 MPa | ||
| 2p: S=23.5 mm (31%) | elongation after aging | ≥ 150 % | ||||
| 3p: S=21.5 mm (33%) | tensile strength after aging | ≥10.5 MPa | ||||
| 4p: S=25.0 mm (36%) | jacket | elongation before aging | ≥ 125 % | |||
| OD | / | tensile strength before aging | ≥ 10 MPa | |||
Inner Assemble | Lay | S=90 ± 5 mm | elongation after aging | ≥ 100 % | ||
| Direction | according to the drawing | tensile strength after aging | ≥ 8 MPa | |||
| OD | / | Packing | ||||
Filler | Ripcord | / | Drum | NA | ||
| Drain Wire | / | |||||
Pair Shield | Shield | Pair Shield | ||||
| Construction | / | |||||
| Material | Polyester/Aluminium (PET/ALU) | |||||
| Coverage | ≥ 115% | |||||
Braid | Material | ɸ 0.12mm Aluminum-magnesium braidedr | ||||
| Coverage | ≥ 40% | |||||
Jacket | Material | LSZH, 60P, -20~75℃ | ||||
| Hardness | 81± 3 | |||||
| OD | 8.5 ± 0.2 | |||||
| Average THK | 0.60 ~ 0.70 | |||||
Color | Yellow | |||||
| Marking Color | black | |||||
| Marking | according to the customer's requirements | |||||
| Construction Item Description | |||
Conductor | Construction | AWG | 23 |
| Material | / | Bare Solid Copper | |
Insulation | Material | / | PE Skin-Foam-Skin |
| Proportion | g/cm³ | / | |
| Outside Diameter | mm | 1.45 ±0.01 | |
| Average Thickness | mm | 0.42 | |
Color | / | 1p: blue stripe + white + blue stripe & blue | |
| 2p: orange stripe + white + orange stripe & orange | |||
| 3p: green stripe + white + green stripe & green | |||
| 4p: brown stripe + white + brown stripe & brown | |||
Pair Twist | Lay & Direction | / | 1p: S=19.0 mm (28%) |
| 2p: S=23.5 mm (31%) | |||
| 3p: S=21.5 mm (33%) | |||
| 4p: S=25.0 mm (36%) | |||
| Inner Assemble | Lay & Direction | / | S=90 ± 5 mm |
Filler | Ripcord | / | / |
| Drain Wire | / | / | |
Pair Shield | Shield | / | Pair Shield |
| Construction | mm | / | |
| Material | / | Polyester/Aluminium (PET/ALU) | |
| Coverage | % | ≥ 115% | |
Braid | Material | / | ɸ 0.12mm Aluminum-magnesium braided |
| Coverage | % | ≥ 40% | |
Jacket | Material | / | LSZH , 60P, -20 ~ 75℃ |
| Hardness | A | 81±3 | |
| Outside Diameter | mm | 8.5 ± 0.2 | |
| Average Thickness | mm | 0.60 ~ 0.70 | |
| Color | / | according to the customer’s requirements | |
| Marking Color | / | Black | |
| Marking | Jacket | / | according to the customer’s requirements |
| Transmission Properties | |||||||||
| CAT7A ANSI/TIA-568.2-D; IEC 61156-6; YD/T1019-2013 | |||||||||
No. | Frequency | Attenuation (Max) | Propagation Delay (Max) | Propagation Delay Skew (Max) | Return Loss (Min) | NEXT (Min) | PS NEXT (Min) | EL-FEXT (Min) | PS EL-FEXT (Min) |
| MHz | dB/100m | ns/100m | ns/100m | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | |
| 1 | 4 | 3.7 | 552 | 25 | 23.0 | 78.0 | 75.0 | 78.0 | 75.0 |
| 2 | 8 | 5.2 | 547 | 25 | 24.5 | 78.0 | 75.0 | 77.2 | 74.2 |
| 3 | 10 | 5.8 | 545 | 25 | 25.0 | 78.0 | 75.0 | 75.3 | 72.3 |
| 4 | 16 | 7.3 | 543 | 25 | 25.0 | 78.0 | 75.0 | 71.2 | 68.2 |
| 5 | 20 | 8.2 | 542 | 25 | 25.0 | 78.0 | 75.0 | 69.3 | 66.3 |
| 6 | 25 | 9.2 | 541 | 25 | 24.3 | 78.0 | 75.0 | 67.3 | 64.3 |
| 7 | 31.25 | 10.3 | 540 | 25 | 23.6 | 78.0 | 75.0 | 65.4 | 62.4 |
| 8 | 62.5 | 14.6 | 539 | 25 | 21.5 | 78.0 | 75.0 | 59.4 | 56.4 |
| 9 | 100 | 18.5 | 538 | 25 | 20.1 | 75.4 | 72.4 | 55.3 | 52.3 |
| 10 | 200 | 26.5 | 537 | 25 | 18.0 | 70.9 | 67.9 | 49.3 | 46.3 |
| 11 | 250 | 29.7 | 536 | 25 | 17.3 | 69.4 | 66.4 | 47.3 | 44.3 |
| 12 | 300 | 32.7 | 536 | 25 | 17.3 | 68.2 | 65.2 | 45.8 | 42.8 |
| 13 | 400 | 38.0 | 536 | 25 | 17.3 | 66.4 | 63.4 | 43.3 | 40.3 |
| 14 | 500 | 42.8 | 536 | 25 | 17.3 | 64.9 | 61.9 | 41.3 | 38.3 |
| 15 | 600 | 47.1 | 535 | 25 | 17.3 | 63.7 | 60.7 | 39.7 | 36.7 |
| 16 | 1000 | 61.9 | 535 | 25 | 15.1 | 60.4 | 57.4 | 35.3 | 32.3 |
ITI-CTSF7A-002 is a CAT7A SFTP Cable with Shielded LSZH Jacket for High Speed Network Connections. It features a vibrant yellow color and a length of 1000Ft. The SFTP shielding offers outstanding protection against interference, making it extremely suitable for high-noise environments. The 23 AWG conductor size effectively reduces attenuation and signal loss, guaranteeing the smooth operation of network connections.
ITI-LINK ITI-CTSF7A-002 is an excellent choice for various
applications. Here are some specific scenarios where this cable can
be effectively utilized:
In summary, ITI-LINK ITI-CTSF7A-002 is a dependable and
high-performing CAT7A Ethernet Cable. Its unique attributes such as
the CAT7A specification, SFTP shielding, LSZH jacket, yellow color,
and 1000Ft length make it suitable for a wide array of occasions
and scenarios. Whether you are constructing a home network, a
commercial network, a data center, or an industrial network, this
cable is well-equipped to fulfill your networking requirements and
ensure the smooth flow of data for high-speed network connections.
Q1: What is the brand name of this cable?
A1: The brand name of this cable is ITI-LINK.
Q2: What is the model number of this cable?
A2: The model number of this cable is ITI-CTSF7A-002.
Q3: Where is this cable manufactured?
A3: This cable is manufactured in SHENZHEN.
Q4: What is the maximum transmission rate of this cable?
A4: This cable can support a maximum transmission rate of up to 10 Gbps.
Q5: Is this cable suitable for outdoor use?
A5: No, this cable is not suitable for outdoor use as it is not waterproof or UV-resistant.
Q6: Are Cat7a Cable interfaces compatible with Cat5e and Cat6 interfaces?
A: The cat7 cable interface is not compatible with the cat5e and cat6 cable interfaces RJ-45, and the cat7 cable requires a separate cat7 dedicated crystal head.
|
|
