| Brand Name : | ITI-LINK |
| Model Number : | ITI-CTSF6A-002 |
| Certification : | UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS |
| Delivery Time : | 15-45 Days |
| Payment Terms : | T/T |
| Supply Ability : | 1000pcs/day |
1.Designed with the latest technology, our 1000ft CAT6A SFTP Yellow LSZH Jacket Cable for High Speed Ethernet Networks provides superior protection against electromagnetic interference. The unique design ensures that your network remains stable and completely free from signal loss, even in complex electromagnetic environments.
2.This 23AWG Cat6a Ethernet Cable is expertly built to handle heavy
data traffic with ease. Whether it's for high - definition video
streaming, large - scale data transfers, or multiple - user online
gaming, it guarantees a smooth and seamless experience for all your
internet - related requirements. The LSZH (Low Smoke Zero Halogen)
jacket material, combined with PVC (Polyvinyl Chloride), not only
provides excellent durability but also gives the cable a sleek and
professional look. More importantly, the LSZH feature ensures
enhanced safety by reducing smoke and toxic gas emissions in case
of fire.
3.Our CAT6A SFTP Cable features a bright yellow jacket color,
making it extremely easy to identify and manage your network
connections within a complex cabling system. The distinct color
stands out, allowing for quick visual recognition during
installation, maintenance, or troubleshooting.
4.Whether you're setting up a brand - new network infrastructure or
upgrading your existing one, our CAT6A SFTP Yellow LSZH Jacket
Cable is the ideal choice to ensure that your network is fast,
reliable, and secure. Additionally, with its user - friendly and
easy - to - install design, you can quickly and effortlessly set up
your network connections without any hassle.
5.So, if you're searching for a high - performance Cat6a Ethernet
Cable that can effortlessly handle all your internet needs, look no
further than our CAT6A SFTP Yellow LSZH Jacket Cable. Order now and
experience the outstanding performance and quality for yourself!
This 305m Cat6A SFTP cable is a high quality LAN cable for high - speed Ethernet Networks. It has a copper conductor for stable signal transmission and a yellow LSZH and PVC jacket for durability and fire - safety. With a Cat6A type and 23AWG conductor size, it ensures fast, reliable data transfer, great for various data - heavy scenarios. The yellow color and LSZH feature make it stand out, an excellent choice for networking setups.
| Cable Type | CAT6A |
| Jacket Color | Yellow |
| Shielding Type | SFTP |
| Frequency | 500MHz |
| Jacket Material | LSZH |
| Conductor Material | Copper |
| Conductor Size | 23AWG |
| Length | 1000FT |
This is an SFTP Cat6A Cable, also known as a CAT LAN Cable or Cat Ethernet Cable.
Product Description: CAT6A SFTP Yellow LSZH Jacket High Speed Network Cable Secure data transmission | ||||||
| Rev.: A | ECN Description: | |||||
| Construction Item Description | Electrical Property | |||||
Conductor | Material | Bare Solid Copper(elongation: 19-24%) | Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m | ||
| OD | 23 AWG | Resistance unbalance within a pair | ≤ 2% | |||
Insulation | Material | PE Skin-Foam-Skin | Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | >1500 MΩ / 100m | ||
| OD | 1.35 ±0.01 mm | Mutual capacitance | 5600 pF / 100m MAX | |||
| Average THK | 0.38 mm | Capacitance unbalance pair to ground at 800Hz or 1 kHz | ≤ 160 pF / 100m | |||
Color | 1p: white + 2 blue stripes & blue | Characteristic impedance at 100MHz | 100 ± 15 Ω | |||
| 2p: white + 2 orange stripes & orange | Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | No breakdown | ||||
| 3p: white + 2 green stripes & green | Mechanical Property | |||||
| 4p: white + 2 brown stripes & brown | insulation | elongation before aging | ≥ 300% | |||
Pair Twist | Lay & Direction | 1p: S=19.0 mm (27%) | tensile strength before aging | ≥12 MPa | ||
| 2p: S=23.5 mm (35%) | elongation after aging | ≥ 150 % | ||||
| 3p: S=21.5 mm (31%) | tensile strength after aging | ≥10.5 MPa | ||||
| 4p: S=27.0 mm (40%) | jacket | elongation before aging | ≥ 125 % | |||
| OD | / | tensile strength before aging | ≥ 10 MPa | |||
Inner Assemble | Lay | S=90 ± 5 mm | elongation after aging | ≥ 100 % | ||
| Direction | according to the drawing | tensile strength after aging | ≥ 8 MPa | |||
| Filler | / | Packing | ||||
| OD | / | Drum | NA | |||
Shield | Shield | Pair Shield | ||||
| Construction | / | |||||
| Material | Aluminium (PET/ALU) | |||||
| Coverage | ≥ 115% | |||||
| Braid | Material | ɸ 0.12mm Aluminum-magnesium braided | ||||
| Coverage | ≥ 40% | |||||
Jacket | Material | LSZH, 60P, -20~75℃ | ||||
| Hardness | 81± 3 | |||||
| OD | 7.5 ± 0.2 | |||||
| Average THK | 0.60 ~ 0.70 | |||||
Color | Yellow | |||||
| Marking Color | black | |||||
| Marking | according to the customer's requirements | |||||
| Electrical Properties | ||
| Conductor Resistance at 20°C | NF EN 50289-1-2 / IEC 60189-1 | ≤ 9.5 Ω / 100m |
| Resistance unbalance within a pair | NF EN 50289-1-2/ IEC 60708 | ≤ 2% |
Dielectric Strength Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | NF EN 50289-1-3 / IEC 61196-1-105 | No breakdown |
| Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | NF EN 50289-1-4 / IEC 60885-1 | >1500 MΩ / 100m |
| Mutual capacitance | NF EN 50289-1-5 /IEC 60189-1 | 5600pF / 100m MAX |
| Capacitance unbalance pair to ground at 800Hz or 1 kHz | NF EN 50289-1-5 / IEC 60189-1 | ≤ 160 pF / 100m |
| Characteristic impedance at 100MHz | NF EN 50289-1-11/ IEC 61156-1 | 100 ± 15 Ω |
| Spark Test | UL444 | 2000 ± 250VOC |
| Transmission Properties | |||||||||
| CAT6A ANSI/TIA-568.2-D; IEC 61156-6; YD/T1019-2013 | |||||||||
No. | Frequency | Attenuation (Max) | Propagation Delay (Max) | Propagation Delay Skew (Max) | Return Loss (Min) | NEXT (Min) | PS NEXT (Min) | EL-FEXT (Min) | PS EL-FEXT (Min) |
| MHz | dB/100m | ns/100m | ns/100m | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | |
| 1 | 4 | 3.8 | 552 | 45 | 23.01 | 66.27 | 63.27 | 55.96 | 52.96 |
| 2 | 8 | 5.31 | 546.73 | 45 | 24.52 | 61.75 | 58.75 | 49.94 | 46.94 |
| 3 | 10 | 5.93 | 545.38 | 45 | 25 | 60.3 | 57.3 | 48 | 45 |
| 4 | 16 | 7.49 | 543 | 45 | 25 | 57.24 | 54.24 | 43.92 | 40.92 |
| 5 | 20 | 8.38 | 542.05 | 45 | 25 | 55.78 | 52.78 | 41.98 | 38.98 |
| 6 | 25 | 9.38 | 541.2 | 45 | 24.32 | 54.33 | 51.33 | 40.04 | 37.04 |
| 7 | 31.25 | 10.5 | 540.44 | 45 | 23.64 | 52.88 | 49.88 | 38.1 | 35.1 |
| 8 | 50 | 13.36 | 539.09 | 45 | 22.21 | 49.82 | 46.82 | 34.02 | 31.02 |
| 9 | 62.5 | 14.99 | 538.55 | 45 | 21.54 | 48.36 | 45.36 | 32.08 | 29.08 |
| 10 | 100 | 19.13 | 537.6 | 45 | 20.11 | 45.3 | 42.3 | 28 | 25 |
| 11 | 125 | 21.51 | 537.22 | 45 | 19.43 | 43.85 | 40.85 | 26.06 | 23.06 |
| 12 | 200 | 27.58 | 536.55 | 45 | 18 | 40.78 | 37.78 | 21.98 | 18.98 |
| 13 | 250 | 31.07 | 536.28 | 45 | 17.32 | 39.33 | 36.33 | 20.04 | 17.04 |
| 14 | 300 | 34.27 | 536.08 | 45 | 17.3 | 38.14 | 35.14 | 18.46 | 15.46 |
| 15 | 350 | 37.25 | 535.92 | 45 | 17.3 | 37.14 | 34.14 | 17.12 | 14.12 |
| 16 | 400 | 40.05 | 535.8 | 45 | 17.3 | 36.27 | 33.27 | 15.96 | 12.96 |
| 17 | 450 | 42.71 | 535.7 | 45 | 17.3 | 35.5 | 32.5 | 14.94 | 11.94 |
| 18 | 500 | 45.26 | 535.61 | 45 | 17.3 | 34.82 | 31.82 | 14.02 | 11.02 |
1.The ITI - LINK CAT6A SFTP Yellow LSZH Jacket Cable is 305m long, making it an excellent choice for a variety of scenarios. In large - scale networking projects like those in data centers, server rooms, and other enterprise - level environments, its length provides the necessary reach. The bright yellow color of the cable allows for easy identification during installation and maintenance within complex cabling systems in these busy environments.
2.With a 23AWG conductor size and 500MHz frequency, this cable is
well - equipped to handle high - bandwidth applications such as
video conferencing, streaming, and online gaming. The LSZH (Low
Smoke Zero Halogen) jacket is a crucial feature, especially in
environments like hospitals in the healthcare industry, schools in
the education sector, banks in the finance field, and government
agencies. In these settings, safety is of utmost importance, and
the LSZH jacket reduces smoke and toxic gas emissions in case of
fire, providing an added layer of protection.
3.This Cat6a Ethernet Cable is suitable for connecting computers,
servers, routers, switches, and other network devices in offices,
schools, hospitals, banks, and government agencies. Its yellow
color makes it stand out among other cables, facilitating quick
recognition during troubleshooting or upgrades.
4.The ITI - LINK ITI - CTSF6A - 002 CAT6A SFTP Yellow LSZH Jacket
Cable is the perfect solution when high - speed data transfer is
essential. It's ideal for businesses of all sizes, from small
enterprises to large corporations, that rely on fast and reliable
network connectivity to keep their operations running smoothly.
Whether it's for daily business transactions, data - intensive
research, or providing services to customers, this cable guarantees
to fulfill your networking requirements.
Q: What is the brand name of the SFTP CAT6A Cable?
A: The brand name of the SFTP CAT6A Cable is ITI-LINK.
Q: What is the model number of the SFTP CAT6A Cable?
A: The model number of the SFTP CAT6A Cable is ITI-CTSF6A-002.
Q: Where is the SFTP CAT6A Cable manufactured?
A: The SFTP CAT6A Cable is manufactured in SHENZHEN.
Q: What is the maximum transmission speed of the SFTP CAT6A Cable?
A: The maximum transmission speed of the SFTP CAT6A Cable is 10Gbps.
Q: What is the length of the SFTP CAT6A Cable?
A: The length of the SFTP CAT6A Cable varies, please check the product description for the available options
Q. Do you have a minimum order quantity limit for network cable
orders?
A: Low MOQ, 1000PCS for sample checking is available.
Q. How do you ship the goods and how long does it take to arrive?
A: We usually ship by sea, which usually takes about 7 days to
arrive.
|
|
