| Brand Name : | ITI-LINK |
| Model Number : | ITI-CTSF6A-004 |
| Certification : | UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS |
| Payment Terms : | T/T |
| Supply Ability : | 1500pcs/day |
| Delivery Time : | 15-45 Days |
1.The Cat 6A Ethernet Cable, specifically the Cat6A SFTP 23AWG LSZH Cable with Blue Jacket For Excellent Signal Transmission and a length of 1000Ft, is a top-notch networking cable. It comprises four individually shielded twisted pairs of copper wire. The SFTP (Shielded and Foiled Twisted Pair) shielding mechanism, a key characteristic, envelops each pair and the entire cable, offering outstanding protection against electromagnetic interference (EMI) and radio frequency interference (RFI). This double-layer shielding guarantees maximum signal integrity and substantially reduces crosstalk between the wires, ensuring a highly stable and reliable connection, which is crucial for excellent signal transmission over the 1000Ft span.
2.The Conductor Material of this Cat 6A LAN Cable is Copper.
Renowned for its high conductivity and low resistance, copper
empowers the cable to transmit data across long distances, like the
full 1000Ft, with minimal signal loss. This property is of great
significance in maintaining data integrity during transmission and
ensuring the network operates at peak efficiency, especially when
handling large volumes of data and demanding excellent signal
transmission.
3.The Jacket Material used in this Cat 6A Ethernet Cable is LSZH
(Low Smoke Zero Halogen). The blue LSZH jacket not only bestows a
unique and easily distinguishable appearance but also provides
excellent protection against environmental elements. Unlike
traditional PVC jackets, LSZH is more environmentally friendly and
offers enhanced safety. It can effectively withstand heat,
moisture, and abrasion, ensuring the 1000Ft cable endures for years
even in harsh conditions, safeguarding the integrity of excellent
signal transmission in diverse circumstances.
4.With a Frequency rating of 500MHz, this CAT6A LAN Cable can
manage high-speed data transfer while preserving signal integrity.
This makes it an ideal choice for high-performance networks that
require reliable and efficient data transfer and excellent signal
transmission. Whether it's for streaming high-definition videos,
conducting large-scale data backups, or running complex network
applications, this cable can meet the demands.
5.The Conductor Size of this Cat 6A Ethernet Cable is 23AWG. This
specific gauge strikes a good balance between signal strength and
flexibility. It enables the cable to be easily routed through tight
spaces and around corners, facilitating installation in any
environment. This flexibility is beneficial in complex network
setups where cables need to be neatly organized and connected
without compromising signal quality, ensuring smooth excellent
signal transmission over the 1000Ft length.
6.In summary, the SFTP CAT6A Cable, namely the Cat6A SFTP 23 AWG
LSZH Cable with Blue Jacket For Excellent Signal Transmission and
1000Ft length, is a premium Ethernet cable. Its Cat 6A LAN Cable
design, Copper Conductor Material, LSZH Jacket Material, 500MHz
Frequency rating, and 23AWG Conductor Size make it an ideal choice
for high-performance networks that necessitate maximum signal
integrity and minimal signal loss to ensure excellent signal
transmission over the extended 1000Ft distance.
| Cable Type: | Cat6a Lan Cable |
| Shielding Type: | Cat6A SFTP Cable |
| Jacket Material: | LSZH |
| Jacket Color: | Blue |
| Conductor Material: | Copper |
| Length: | 1000Feet |
| Frequency: | 500MHz |
| Conductor Size: | 23AWG |
Product Description: Cat6A SFTP 23 AWG LSZH Cable with Blue Jacket For Excellent Signal Transmission | ||||||
| Rev.: A | ECN Description: | |||||
| Construction Item Description | Electrical Property | |||||
Conductor | Material | Bare Solid Copper(elongation: 19-24%) | Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m | ||
| OD | 23 AWG | Resistance unbalance within a pair | ≤ 2% | |||
Insulation | Material | PE Skin-Foam-Skin | Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | >1500 MΩ / 100m | ||
| OD | 1.35 ±0.01 mm | Mutual capacitance | 5600 pF / 100m MAX | |||
| Average THK | 0.38 mm | Capacitance unbalance pair to ground at 800Hz or 1 kHz | ≤ 160 pF / 100m | |||
Color | 1p: white + 2 blue stripes & blue | Characteristic impedance at 100MHz | 100 ± 15 Ω | |||
| 2p: white + 2 orange stripes & orange | Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | No breakdown | ||||
| 3p: white + 2 green stripes & green | Mechanical Property | |||||
| 4p: white + 2 brown stripes & brown | insulation | elongation before aging | ≥ 300% | |||
Pair Twist | Lay & Direction | 1p: S=19.0 mm (27%) | tensile strength before aging | ≥12 MPa | ||
| 2p: S=23.5 mm (35%) | elongation after aging | ≥ 150 % | ||||
| 3p: S=21.5 mm (31%) | tensile strength after aging | ≥10.5 MPa | ||||
| 4p: S=27.0 mm (40%) | jacket | elongation before aging | ≥ 125 % | |||
| OD | / | tensile strength before aging | ≥ 10 MPa | |||
Inner Assemble | Lay | S=90 ± 5 mm | elongation after aging | ≥ 100 % | ||
| Direction | according to the drawing | tensile strength after aging | ≥ 8 MPa | |||
| Filler | / | Packing | ||||
| OD | / | Drum | NA | |||
Shield | Shield | Pair Shield | ||||
| Construction | / | |||||
| Material | Aluminium (PET/ALU) | |||||
| Coverage | ≥ 115% | |||||
| Braid | Material | ɸ 0.12mm Aluminum-magnesium braided | ||||
| Coverage | ≥ 40% | |||||
Jacket | Material | LSZH, 60P, -20~75℃ | ||||
| Hardness | 81± 3 | |||||
| OD | 7.5 ± 0.2 | |||||
| Average THK | 0.60 ~ 0.70 | |||||
Color | Blue | |||||
| Marking Color | black | |||||
| Marking | according to the customer's requirements | |||||
| Electrical Properties | ||
| Conductor Resistance at 20°C | NF EN 50289-1-2 / IEC 60189-1 | ≤ 9.5 Ω / 100m |
| Resistance unbalance within a pair | NF EN 50289-1-2/ IEC 60708 | ≤ 2% |
Dielectric Strength Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | NF EN 50289-1-3 / IEC 61196-1-105 | No breakdown |
| Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | NF EN 50289-1-4 / IEC 60885-1 | >1500 MΩ / 100m |
| Mutual capacitance | NF EN 50289-1-5 /IEC 60189-1 | 5600pF / 100m MAX |
| Capacitance unbalance pair to ground at 800Hz or 1 kHz | NF EN 50289-1-5 / IEC 60189-1 | ≤ 160 pF / 100m |
| Characteristic impedance at 100MHz | NF EN 50289-1-11/ IEC 61156-1 | 100 ± 15 Ω |
| Spark Test | UL444 | 2000 ± 250VOC |
| Transmission Properties | |||||||||
| CAT6A ANSI/TIA-568.2-D; IEC 61156-6; YD/T1019-2013 | |||||||||
No. | Frequency | Attenuation (Max) | Propagation Delay (Max) | Propagation Delay Skew (Max) | Return Loss (Min) | NEXT (Min) | PS NEXT (Min) | EL-FEXT (Min) | PS EL-FEXT (Min) |
| MHz | dB/100m | ns/100m | ns/100m | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | |
| 1 | 4 | 3.8 | 552 | 45 | 23.01 | 66.27 | 63.27 | 55.96 | 52.96 |
| 2 | 8 | 5.31 | 546.73 | 45 | 24.52 | 61.75 | 58.75 | 49.94 | 46.94 |
| 3 | 10 | 5.93 | 545.38 | 45 | 25 | 60.3 | 57.3 | 48 | 45 |
| 4 | 16 | 7.49 | 543 | 45 | 25 | 57.24 | 54.24 | 43.92 | 40.92 |
| 5 | 20 | 8.38 | 542.05 | 45 | 25 | 55.78 | 52.78 | 41.98 | 38.98 |
| 6 | 25 | 9.38 | 541.2 | 45 | 24.32 | 54.33 | 51.33 | 40.04 | 37.04 |
| 7 | 31.25 | 10.5 | 540.44 | 45 | 23.64 | 52.88 | 49.88 | 38.1 | 35.1 |
| 8 | 50 | 13.36 | 539.09 | 45 | 22.21 | 49.82 | 46.82 | 34.02 | 31.02 |
| 9 | 62.5 | 14.99 | 538.55 | 45 | 21.54 | 48.36 | 45.36 | 32.08 | 29.08 |
| 10 | 100 | 19.13 | 537.6 | 45 | 20.11 | 45.3 | 42.3 | 28 | 25 |
| 11 | 125 | 21.51 | 537.22 | 45 | 19.43 | 43.85 | 40.85 | 26.06 | 23.06 |
| 12 | 200 | 27.58 | 536.55 | 45 | 18 | 40.78 | 37.78 | 21.98 | 18.98 |
| 13 | 250 | 31.07 | 536.28 | 45 | 17.32 | 39.33 | 36.33 | 20.04 | 17.04 |
| 14 | 300 | 34.27 | 536.08 | 45 | 17.3 | 38.14 | 35.14 | 18.46 | 15.46 |
| 15 | 350 | 37.25 | 535.92 | 45 | 17.3 | 37.14 | 34.14 | 17.12 | 14.12 |
| 16 | 400 | 40.05 | 535.8 | 45 | 17.3 | 36.27 | 33.27 | 15.96 | 12.96 |
| 17 | 450 | 42.71 | 535.7 | 45 | 17.3 | 35.5 | 32.5 | 14.94 | 11.94 |
| 18 | 500 | 45.26 | 535.61 | 45 | 17.3 | 34.82 | 31.82 | 14.02 | 11.02 |
1.The ITI-CTSF6A-004 SFTP Cat6A Cable, which is a Cat6A SFTP 23 AWG LSZH Cable with Blue Jacket For Excellent Signal Transmission and has a length of 1000Ft, can handle a frequency of up to 500 MHz. This enables it to be suitable for high-bandwidth applications that demand excellent signal transmission. The 23 AWG conductor size strikes a perfect balance between signal strength and flexibility, ensuring that it can manage high-speed data transfer with minimal signal loss, which is essential for maintaining excellent signal integrity.
2.The LSZH (Low Smoke Zero Halogen) jacket material, instead of
traditional PVC, offers enhanced safety and environmental
friendliness. It can withstand various environmental challenges,
making it highly durable and long-lasting even in harsh conditions.
The blue color of the jacket not only gives it a distinct and
recognizable appearance but also aids in easy identification and
cable management during installation and maintenance.
3.This cable is applicable in a wide range of scenarios. In a home
environment, it can be used to connect gaming consoles, streaming
devices, and other internet-enabled devices. The excellent signal
transmission capability ensures a seamless and lag-free experience
for online gaming and high-definition video streaming. In an office
setting, it can link computers, servers, printers, and other
networked equipment, providing a stable and reliable network
connection for daily business operations.
4.For data centers and server rooms, the ITI-CTSF6A-004 cable is an
ideal choice. It can interconnect servers and other networking
gear, guaranteeing reliable and efficient data transfer. The SFTP
shielding is highly effective in areas with significant
electromagnetic interference, safeguarding the integrity of data
transmission and ensuring excellent signal quality. The 1000Ft
length is convenient for large-scale installations, allowing for
flexible cable routing and connection between different components
within the data center or commercial building.
5.In summary, the ITI-CTSF6A-004 SFTP Cat6A Cable from ITI-LINK is
a dependable and efficient option for high-speed internet
connections and data transfer. Whether it's for domestic use,
office networking, or in data centers, this cable, with its Cat6A
standard, SFTP shielding, 23 AWG conductor, LSZH jacket, blue
color, and 1000Ft length, is certain to deliver the performance and
durability required for excellent signal transmission.
Q: What is the brand name of this SFTP CAT6A cable?
A: The brand name of this SFTP CAT6A cable is ITI-LINK.
Q: What is the model number of this SFTP CAT6A cable?
A: The model number of this SFTP CAT6A cable is ITI-CTSF6A-004.
Q: Where is this SFTP CAT6A cable manufactured?
A: This SFTP CAT6A cable is manufactured in SHENZHEN.
Q: What is the maximum data transfer speed of this SFTP CAT6A cable?
A: This SFTP CAT6A cable supports data transfer speeds of up to 10Gbps.
Q: Is this SFTP CAT6A cable suitable for outdoor use?
A: No, this SFTP CAT6A cable is not suitable for outdoor use as it is not designed to withstand exposure to the elements.
|
|
