Wholesale 10Gbps IEC60332-1 CAT 6A F FTP 23AWG LSZH Cable 500MHz Solid Twin Cable

Ask Lasest Price
Brand Name :	ITI-LINK
Model Number :	ITI-CTF6A-004
Certification :	UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
Delivery Time :	15-45 Days
Payment Terms :	T/T
Supply Ability :	1000pcs/day

Add to Cart

Product Details
Company Profile

Wholesale 10Gbps IEC60332-1 CAT 6A F FTP 23AWG LSZH Cable 500MHz Solid Twin Cable

Wholesale CAT6A FFTP 23AWG LSZH Cable 500MHz Solid Twin-Cable 10Gbps IEC60332-1

Product Description:

1.Introducing the ITI-CTF6A-004 FFTP Cat6A 23AWG Cable—a 1000Ft networking solution engineered for peak performance. Its HDPE (High-Density Polyethylene) insulation ensures Cat6A-level electrical stability, supporting 500MHz frequency and 10Gbps speeds. The solid twin-cable design, combined with FFTP (Foil Foil Twisted Pair) shielding, minimizes crosstalk and EMI, making this Cat6A FFTP cable ideal for high-bandwidth applications like data centers and industrial automation.

2.Clad in a gray LSZH (Low Smoke Zero Halogen) jacket, the ITI-CTF6A-004 stands out in complex networks while meeting IEC60332-1 fire safety standards. The LSZH material not only reduces toxic fume emissions during fires but also enhances physical durability against abrasion and moisture. This Cat6A FFTP cable’s gray coloring streamlines cable management in enterprise setups, while its LSZH compliance ensures safety in high-occupancy environments like offices or educational institutions.

3.Designed as a pure FFTP Cat6A solution, this cable features dual-layer foil shielding to combat electromagnetic interference—a critical advantage in noisy industrial sites or near heavy machinery. Unlike standard Cat6A cables, the FFTP architecture ensures signal integrity across its 1000Ft length, making it suitable for long-haul network deployments. The ITI-CTF6A-004’s 23AWG conductors and Cat6A certification guarantee reliable 10Gbps transmission up to 100 meters, aligning with modern gigabit infrastructure demands.

4.The ITI-CTF6A-004 FFTP Cat6A Cable delivers unmatched scalability for large-scale networks. Its 1000Ft roll provides flexibility to span across floors or buildings, while the FFTP shielding maintains low latency in high-traffic environments. The LSZH jacket adds an extra layer of protection, future-proofing against evolving fire regulations in data centers and commercial complexes. With Cat6A performance and FFTP reliability, this cable is essential for applications requiring both speed and safety.

5.In summary, the ITI-CTF6A-004 embodies the pinnacle of Cat6A FFTP technology: HDPE insulation for signal purity, LSZH fire safety for compliance, and a 1000Ft length for versatile installations. Whether upgrading a data center’s backbone or deploying an industrial IoT network, this Cat6A FFTP cable with LSZH jacket ensures fast, secure, and future-ready connectivity. Trust the ITI-CTF6A-004 to meet the rigorous demands of mission-critical Cat6A environments..

Technical Parameters:

Cable Type	FFTP
Category	CAT6A Ethernet Cable
Length	1000Ft
Color	Gray
Jacket Material	LSZH
Frequency	500MHz
Insulation Material	HDPE
Conductor Size	23 AWG

Product Description: CAT6A FFTP 23AWG LSZH Cable 500MHz Solid Twin-Cable 10Gbps IEC60332-1
Rev.: A		ECN Description:
Construction Item Description			Electrical Property
Conductor	Material	Bare Solid Copper(elongation: 19-24%)	Conductor Resistance at 20°C			≤ 9.5 Ω / 100m
	OD	23AWG	Resistance unbalance within a pair			≤ 2%
Insulation	Material	PE Skin-Foam-Skin	Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V			>1500 MΩ / 100m
	OD	1.35 ±0.01 mm	Mutual capacitance			5600 pF / 100m MAX
	Average THK	0.385 mm	Capacitance unbalance pair to ground at 800Hz or 1 kHz			≤ 160 pF / 100m
	Color	1p: white + 2 blue stripes & blue	Characteristic impedance at 100MHz			100 ± 15 Ω
		2p: white + 2 orange stripes & orange	Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min			No breakdown
		3p: white + 2 green stripes & green	Mechanical Property
		4p: white + 2 brown stripes & brown	insulation	elongation before aging		≥ 200%
Pair Twist	Lay & Direction	1p: S=19.0 mm (27%)		tensile strength before aging		≥10 MPa
		2p: S=23.5 mm (35%)		elongation after aging		≥ 150 %
		3p: S=21.5 mm (31%)		tensile strength after aging		≥ 9 MPa
		4p: S=27.0 mm (40%)	jacket	elongation before aging		≥ 125 %
	OD	/		tensile strength before aging		≥ 10 MPa
Inner Assemble	Lay	S=100 ± 5 mm		elongation after aging		≥ 100 %
	Direction	according to the drawing		tensile strength after aging		≥ 8 MPa
	Filler	/	Packing
	OD	/	Drum		NA
Filler	Ripcord	300D
	Drain Wire	Tinned Copper
Shield	Shield	Pair Shield & Aluminium Foil
	Construction	/
	Material	Aluminium (PET/ALU)
	Coverage	≥ 115%
Jacket	Material	LSZH
	Hardness	NA
	OD	7.6 ± 0.2
	Average THK	0.60 ~ 0.70
	Color	Gray
	Marking Color	black
Marking		according to the customer's requirements

Electrical Properties
Conductor Resistance at 20°C	NF EN 50289-1-2 / IEC 60189-1	≤ 9.5 Ω / 100m
Resistance unbalance within a pair	NF EN 50289-1-2/ IEC 60708	≤ 5%
Dielectric Strength Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min	NF EN 50289-1-3 / IEC 61196-1-105	No breakdown
Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V	NF EN 50289-1-4 / IEC 60885-1	>1500 MΩ / 100m
Mutual capacitance	NF EN 50289-1-5 /IEC 60189-1	5600pF / 100m MAX
Capacitance unbalance pair to ground at 800Hz or 1 kHz	NF EN 50289-1-5 / IEC 60189-1	≤ 160 pF / 100m
Characteristic impedance at 100MHz	NF EN 50289-1-11/ IEC 61156-1	100 ± 15 Ω
Spark Test	UL444	2000 ± 250VOC

Transmission Properties
CAT6A F/FTP
No.	Frequency	Attenuation (Max)	Propagation Delay (Max)	Propagation Delay Skew (Max)	Return Loss (Min)	NEXT (Min)	PS NEXT (Min)	EL-FEXT (Min)	PS EL-FEXT (Min)
No.	MHz	dB/100m	ns/100m	ns/100m	dB(on 100m)	dB(on 100m)	dB(on 100m)	dB(on 100m)	dB(on 100m)
1	4	3.8	552	45	23.01	66.27	63.27	55.96	52.96
2	8	5.31	546.73	45	24.52	61.75	58.75	49.94	46.94
3	10	5.93	545.38	45	25	60.3	57.3	48	45
4	16	7.49	543	45	25	57.24	54.24	43.92	40.92
5	20	8.38	542.05	45	25	55.78	52.78	41.98	38.98
6	25	9.38	541.2	45	24.32	54.33	51.33	40.04	37.04
7	31.25	10.5	540.44	45	23.64	52.88	49.88	38.1	35.1
8	50	13.36	539.09	45	22.21	49.82	46.82	34.02	31.02
9	62.5	14.99	538.55	45	21.54	48.36	45.36	32.08	29.08
10	100	19.13	537.6	45	20.11	45.3	42.3	28	25
11	125	21.51	537.22	45	19.43	43.85	40.85	26.06	23.06
12	200	27.58	536.55	45	18	40.78	37.78	21.98	18.98
13	250	31.07	536.28	45	17.32	39.33	36.33	20.04	17.04
14	300	34.27	536.08	45	17.3	38.14	35.14	18.46	15.46
15	350	37.25	535.92	45	17.3	37.14	34.14	17.12	14.12
16	400	40.05	535.8	45	17.3	36.27	33.27	15.96	12.96
17	450	42.71	535.7	45	17.3	35.5	32.5	14.94	11.94
18	500	45.26	535.61	45	17.3	34.82	31.82	14.02	11.02

Applications:

Whether you’re setting up a home network, small office, or large-scale data center, the ITI-CTF6A-004 CAT6A FFTP 23AWG LSZH Cable is an outstanding choice. With Cat6A-certified 500MHz frequency, 23AWG conductors, and solid twin-cable design, this FFTP (Foil-Shielded Twisted Pair) cable delivers reliable 10Gbps performance over long distances. The LSZH jacket adds fire-safe durability, making it ideal for modern networking demands.

Versatile Applications of ITI-CTF6A-004 CAT6A FFTP LSZH Cable

Residential Networks

In homes, the gray LSZH-jacketed ITI-CTF6A-004 stands out for both aesthetics and safety. The Cat6A FFTP design ensures lag-free connectivity for gaming, 4K streaming, and IoT devices, while the LSZH material prevents toxic fume emissions in fire scenarios. Its 1000Ft length allows flexible routing across rooms, with the FFTP shielding minimizing interference from household electronics.

Small Office Setups

For small offices, the ITI-CTF6A-004 CAT6A FFTP Cable enhances productivity with stable 500MHz data transmission. The FFTP architecture reduces crosstalk between computers, printers, and servers, while the gray LSZH jacket simplifies cable management in tight spaces. Compliance with IEC60332-1 ensures LSZH-based fire safety, critical for office environments with dense equipment.

Data Centers & Industrial Projects

In data centers, the ITI-CTF6A-004 excels with its Cat6A FFTP technology:

1000Ft Length: Spans server racks and cross-connects in large facilities.
10Gbps/500MHz Performance: Handles high-bandwidth tasks like cloud computing and real-time data analytics.
Dual FFTP Shielding: Blocks EMI/RFI from power systems and heavy machinery.
LSZH Compliance: Meets strict fire codes, reducing smoke and halogen gas risks in mission-critical environments.

Installation & Performance

The ITI-CTF6A-004 CAT6A FFTP LSZH Cable features a user-friendly design:

Gray LSZH Jacket: Enhances visibility in complex cabling systems.
Solid Twin-Cable Structure: Maintains signal integrity during installation and maintenance.
Cat6A Certification: Guarantees future-proof compatibility with 10GBASE-T networks.

Conclusion:
The ITI-CTF6A-004 is more than a cable—it’s a Cat6A FFTP solution engineered for speed, safety, and scalability. Whether upgrading a home network or deploying a data center backbone, its LSZH fire resistance, FFTP interference protection, and Cat6A performance make it the ultimate choice for reliable, future-ready connectivity.

FAQ:

1.Q: What is the brand name of this Category 6A cable?

A: The brand name of this CAT6A cable is ITI-LINK .

2. Q: What is the model number of this CAT6A cable?

A: The model number of this CAT6A cable is ITI-CTF6A-004.

3. Q: Where is this CAT6A cable manufactured?

A: This CAT6A cable is manufactured in SHENZHEN .

4. Q: What is the maximum data transfer rate of this CAT6A cable?

A: This CAT6A cable can support data transfer rates of up to 10Gbps .

5. Q: Is this CAT6A cable suitable for outdoor use?

A: No, this CAT6A cable is not suitable for outdoor use as it is designed for indoor applications only.
