| Brand Name : | ITI-LINK |
| Model Number : | ITI-C6AU-001 |
| Certification : | UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS |
| Delivery Time : | 15-45 Days |
| Payment Terms : | T/T |
| Supply Ability : | 1500pcs/day |
1.The conductor size of this CAT6A UTP 23AWG 500MHz LSZH AXT PASSED CPR B2ca Ethernet Cable 1000Ft is 23AWG, endowing it with the capability of high - speed data transmission. With a frequency rating of 500 MHz, it can manage vast amounts of data traffic without any signal loss. This makes it perfect for applications demanding high - speed data transfer, like online gaming, video streaming, and file sharing.
2.The yellow - colored jacket of this cable not only enables easy
identification among a bunch of cables but also adds a stylish
touch to your network setup. This cable is crafted from high -
quality materials, ensuring durability and a long lifespan. It's
designed to endure wear and tear, making it highly suitable for
areas where cables are often moved or adjusted.
3.What's more, this cable is made of low - smoke, zero - halogen
(LSZH) material. In case of a fire, it emits very little smoke and
no halogen gas, which is of great significance for protecting the
environment and people's lives. It has passed the AXT test, which
is a strong proof of its excellent quality and reliable
performance. Moreover, it complies with the CPR (Construction
Products Regulation) and has achieved the B2ca grade. This means it
meets strict European safety and performance requirements for
construction products, making it safe and reliable for use in
various building environments.
4.The UTP CAT6A Cable belongs to the CAT6 Ethernet Cable family, so
it's designed to fulfill the stringent standards of the industry.
It's backward - compatible with Cat Ethernet Cable and Cat6A
Ethernet Cable, allowing it to be used with older devices without
any compatibility problems.
5.This cable is easy to install and use. It comes with clear
instructions that even non - technical users can follow to set up
their network infrastructure with ease. Additionally, it's simple
to maintain, enabling you to focus on other aspects of your network
without concerns about the cable.
6.In conclusion, if you're seeking a reliable and fast Ethernet
cable for your home or office network, this CAT6A UTP 23AWG 500 MHz
LSZH AXT PASSED CPR B2ca Ethernet Cable 1000Ft is an outstanding
choice. With its 1000 - foot length, 23 - AWG conductor size, 500 -
MHz frequency rating, and yellow - jacket color, it's bound to meet
all your network requirements. And being part of the CAT6 Ethernet
Cable family, it's compatible with older devices. So don't
hesitate. Get your UTP CAT6A Cable today and enjoy the advantages
of a fast and reliable network connection!
This 1000 - Ft CAT6A UTP 23AWG 500 MHz LSZH AXT - passed CPR B2ca Ethernet Cable is for various networking apps. Its UTP design enables reliable data transmission. The LSZH jacket offers durability and safety, emitting little smoke and no halogen gases in a fire for people and equipment protection.With 500 MHz frequency and 23AWG conductors, it handles data efficiently. The yellow jacket is distinguishable. Passing AXT test and meeting CPR B2ca grade show its quality, making it ideal for demanding networking environments.
| Cable Type | UTP |
| Length | 1000 Ft |
| Jacket Material | LSZH |
| Conductor Size | 23 AWG |
| Category | CAT6A |
| Frequency | 500MHz |
| Jacket Color | Yellow |
| Conductor Material | Copper |
Product Description: CAT6A UTP 23AWG 500 MHz LSZH AXT PASSED CPR B2ca Ethernet Cable 1000Ft | |
| Rev.:A | ECN Description: |
| Construction Item Description | Electrical Properties | |||||
Conductor | Material | Oxygen-Free Bare Solid Copper | Single Conductor DC Resistance,Max,20℃ | 9.5Ω/100m | ||
| Elongation | ≥15% | Conductor DC Resistance Imbalance,Max,20℃ | ≤2% | |||
| OD | 23AWG | Pairs DC Resistance Imbalance,Max,20℃ | ≤4% | |||
Insulation | Material | HDPE 8303 | Delay Skew,1-250MHz,Max | 45ns/100m | ||
| OD | 1.01±0.02 | Velocity of Propagation | 69% | |||
| Average THK | 0.21mm | Insulation Resistance(CD/CD),DC100-500V,Min | 5000MΩ.km | |||
Color | 1p: white + 2 blue stripes & blue | Pair To Ground Capacitance Unbalance,Max,0.8KHz∕1KHz | 160pF/100m | |||
2p: white + 2 orange stripes & orange | Dielectric Strength(CD/CD):2.5KV DC for 2 seconds or 1KV DC for 1 minute | No Breakdown | ||||
3p: white + 2 green stripes & green | Mechanical Property | |||||
4p: white + 2 brown stripes & brown | insulation | elongation before aging | ≥ 300% | |||
Pair Twist | Lay&Direction | 1p:S=15.5mm(26%) | tensile strength before aging | ≥16 MPa | ||
| 2p:S=11.0mm(19%) | jacket | elongation before aging | ≥ 150 % | |||
| 3p:S=14.0mm(24%) | tensile strength before aging | ≥10.5 MPa | ||||
| 4p:S=12.5mm(21%) | elongation after aging | ≥ 125 % | ||||
Inner Assemble | Lay | S=90±5mm | tensile strength after aging | ≥ 10 MPa | ||
| Direction | according to the drawing | Packing | ||||
| Filler | 5.0±0.1mm x 0.5±0.01mm | |||||
| OD | / | Drum | NA | |||
Filler | Material | Ripcord | ||||
| Construction | 300D | |||||
Outside Shield | Shield | / | ||||
| Construction | / | |||||
| Material | / | |||||
| Coverage | / | |||||
Jacket | Material | LSZH | ||||
| Hardness | 81A±3A | |||||
| OD | 7.0±0.5mm | |||||
| Average THK | 0.7mm+Gear | |||||
| Color | Yellow | |||||
| Marking Color | according to the customer's requirements | |||||
| Marking | according to the customer's requirements | |||||
| Electrical Properties | ||
| Single Conductor DC Resistance,Max,20℃(Ω/100m) | NF EN 50289 | 9.5 |
| Conductor DC Resistance Imbalance,Max,20℃(%) | ≤2 | |
| Pairs DC Resistance Imbalance,Max,20℃(%) | ≤4 | |
Dielectric Strength Conductor/Conductor:2.5KV DC for 2 seconds or 1KV DC for 1 minute | No Breakdown | |
Insulation Resistance Insulation Resistance(Conductor/Conductor),DC100-500V,Min(MΩ.km) | 5000 | |
| Pair To Ground Capacitance Unbalance,Max,0.8KHz∕1KHz(pF/100m) | 160 | |
| Delay Skew,1-250MHz,Max(ns/100m) | 45 | |
| Velocity of Propagation(%) | 69 | |
| Electrical Properties | ||
| Single Conductor DC Resistance,Max,20℃(Ω/100m) | NF EN 50289 | 9.5 |
| Conductor DC Resistance Imbalance,Max,20℃(%) | ≤2 | |
| Pairs DC Resistance Imbalance,Max,20℃(%) | ≤4 | |
Dielectric Strength Conductor/Conductor:2.5KV DC for 2 seconds or 1KV DC for 1 minute | No Breakdown | |
Insulation Resistance Insulation Resistance(Conductor/Conductor),DC100-500V,Min(MΩ.km) | 5000 | |
| Pair To Ground Capacitance Unbalance,Max,0.8KHz∕1KHz(pF/100m) | 160 | |
| Delay Skew,1-250MHz,Max(ns/100m) | 45 | |
| Velocity of Propagation(%) | 69 | |
| Transmission Performance | |||||||||
Freq | Characteristic Impedance Upper Limit | Characteristic Impedance Lower Limit | RL | ATT | NEXT | PS NEXT | EL FEXT | PS ELFEXT | Propagation Delay |
| MHz | Ω | Ω | dB | dB/100m | dB/100m | dB/100m | dB/100m | dB/100m | ns/100m |
| 4 | 115.2 | 86.8 | ≥23 | ≤3.8 | ≥66.3 | ≥63.3 | ≥56 | ≥53 | ≤552 |
| 8 | 112.6 | 88.8 | ≥24.5 | ≤5.3 | ≥61.8 | ≥58.8 | ≥49.9 | ≥46.9 | ≤547 |
| 10 | 111.9 | 89.4 | ≥25 | ≤5.9 | ≥60.3 | ≥57.3 | ≥48 | ≥45 | ≤545 |
| 16 | 111.9 | 89.4 | ≥25 | ≤7.5 | ≥57.2 | ≥54.2 | ≥43.9 | ≥40.9 | ≤543 |
| 20 | 111.9 | 89.4 | ≥25 | ≤8.4 | ≥55.8 | ≥52.8 | ≥42 | ≥39 | ≤542 |
| 25 | 112.9 | 88.5 | ≥24.3 | ≤9.4 | ≥54.3 | ≥51.3 | ≥40 | ≥37 | ≤541 |
| 31.25 | 114.1 | 87.7 | ≥23.6 | ≤10.5 | ≥52.9 | ≥49.9 | ≥38.1 | ≥35.1 | ≤540 |
| 62.5 | 118.3 | 84.5 | ≥21.5 | ≤15 | ≥48.4 | ≥45.4 | ≥32.1 | ≥29.1 | ≤539 |
| 100 | 121.9 | 82 | ≥20.1 | ≤19.1 | ≥45.3 | ≥42.3 | ≥28 | ≥25 | ≤538 |
| 200 | 128.8 | 77.6 | ≥18 | ≤27.6 | ≥40.8 | ≥37.8 | ≥22 | ≥19 | ≤537 |
| 250 | 131.6 | 76 | ≥17.3 | ≤31.1 | ≥39.3 | ≥36.3 | ≥20 | ≥17 | ≤536 |
| 300 | 133.7 | 74.7 | ≥17.3 | ≤34.3 | ≥38.1 | ≥35.1 | ≥18.5 | ≥15.5 | ≤536 |
| 400 | 138.2 | 72.4 | ≥17.3 | ≤40.1 | ≥36.3 | ≥33.3 | ≥16 | ≥13 | ≤536 |
| 500 | 142 | 70.4 | ≥17.3 | ≤45.3 | ≥34.8 | ≥31.8 | ≥14 | ≥11 | ≤536 |
The CAT6A UTP 23AWG 500MHz LSZH AXT PASSED CPR B2ca Ethernet Cable 1000Ft is built with 23 AWG copper conductors, providing outstanding conductivity and signal quality. Its LSZH jacket material not only offers protection against damage but also enhances safety. In case of a fire, it emits little smoke and no halogen gases, safeguarding both people and equipment. This feature is especially crucial in various environments, maintaining signal integrity even in harsh conditions. With a frequency rating of 500 MHz, this cable can handle high - bandwidth data traffic with ease, making it perfect for high - speed networking applications.
This yellow - colored cable is an excellent choice whether you're
establishing a small home network or a large enterprise network.
It's suitable for a wide variety of applications and scenarios,
including:
Moreover, in public facilities like schools and hospitals, the LSZH
property provides an added layer of safety. In educational
institutions, the yellow cable can be color - coded for different
departments or functions. In hospitals, its visibility and safety
features are beneficial during emergency situations or maintenance
work.
With a length of 1000 ft, this cable provides sufficient coverage
for most networking applications. Its high - quality build and
excellent performance make it a dependable and cost - effective
option for those in need of a high - speed networking cable. Order
yours today and upgrade your network!
Q: What is the brand name of this product?
A: The brand name of this product is ITI-LINK.
Q: What is the model number of this product?
A: The model number of this product is ITI-C6AU-001.
Q: Where is this product manufactured?
A: This product is manufactured in SHENZHEN.
Q: What is the maximum data transfer rate of this cable?
A: This cable is a UTP CAT6A Cable which can support data transfer rates of up to 10Gbps.
Q: Is this cable suitable for outdoor use?
A: No, this cable is not suitable for outdoor use as it is not designed to withstand exposure to environmental elements.
|
|
