| Brand Name : | ITI-LINK |
| Model Number : | ITI-C6AU-002 |
| Certification : | UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS |
| Delivery Time : | 15-45 Days |
| Payment Terms : | T/T |
| Supply Ability : | 1500pcs/day |
1.The CAT6A UTP 23AWG Bare Solid Copper LSZH CPR B2ca 10Gbps Network Cable 1000FT is designed with precision to support high - speed data transfer rates of up to 10 Gbps. This remarkable capability makes it perfect for environments where high - bandwidth is essential, such as data centers, server farms, and other highly demanding networking scenarios. This cable is backward - compatible with Cat5e and Cat6 cables, offering a seamless upgrade solution for existing network infrastructures.
2.The Cat6A UTP Cable features a frequency rating of 500 MHz. This
enables it to effortlessly support high - bandwidth applications
including video streaming and online gaming. It is ingeniously
designed to minimize crosstalk, ensuring the accurate and
interference - free transmission of data. This significantly
enhances network performance and reliability.
3.The UTP CAT6A Cable is not only straightforward to install but
also comes in a durable, pull - box packaging that facilitates easy
storage and transportation. It complies with the RoHS standard,
meeting the latest environmental and safety requirements. Moreover,
this cable is Low - Smoke Zero - Halogen (LSZH). In the event of a
fire, it emits very little smoke and no halogen gases, safeguarding
both people and equipment. It meets the Construction Products
Regulation (CPR) standard with a B2ca rating, which attests to its
high quality and safety in construction - related applications. Its
blue jacket color not only gives it an appealing look but also aids
in easy identification during installation and maintenance
processes.
4.In summary, the UTP CAT6A Cable is a top - notch, high -
performance Cat6a Ethernet Cable engineered to support high - speed
data transfer rates of up to 10 Gbps. It is highly suitable for use
in demanding networking environments like data centers and server
farms, and is backward - compatible with Cat5e and Cat6 cables.
With a frequency rating of 500 MHz, a blue jacket, along with its
LSZH and CPR B2ca compliance, this 1000 - foot cable is a reliable
and durable option for all your networking needs.
| Category: | CAT6A |
| Cable Type: | UTP |
| Jacket Material: | LSZH |
| Jacket Color: | Blue |
| Conductor Material: | Copper |
| Conductor Size: | 23 AWG |
| Frequency: | 500MHz |
| Length: | 1000Ft |
Product Description: CAT6A UTP 23AWG Bare Solid Copper LSZH CPR B2ca 10Gbps Network Cable 1000FT | |
| Rev.:A | ECN Description: |
| Construction Item Description | Electrical Properties | |||||
Conductor | Material | Oxygen-Free Bare Solid Copper | Single Conductor DC Resistance,Max,20℃ | 9.5Ω/100m | ||
| Elongation | ≥15% | Conductor DC Resistance Imbalance,Max,20℃ | ≤2% | |||
| OD | 23AWG | Pairs DC Resistance Imbalance,Max,20℃ | ≤4% | |||
Insulation | Material | HDPE 8303 | Delay Skew,1-250MHz,Max | 45ns/100m | ||
| OD | 1.01±0.02 | Velocity of Propagation | 69% | |||
| Average THK | 0.21mm | Insulation Resistance(CD/CD),DC100-500V,Min | 5000MΩ.km | |||
Color | 1p: white + 2 blue stripes & blue | Pair To Ground Capacitance Unbalance,Max,0.8KHz∕1KHz | 160pF/100m | |||
2p: white + 2 orange stripes & orange | Dielectric Strength(CD/CD):2.5KV DC for 2 seconds or 1KV DC for 1 minute | No Breakdown | ||||
3p: white + 2 green stripes & green | Mechanical Property | |||||
4p: white + 2 brown stripes & brown | insulation | elongation before aging | ≥ 300% | |||
Pair Twist | Lay&Direction | 1p:S=15.5mm(26%) | tensile strength before aging | ≥16 MPa | ||
| 2p:S=11.0mm(19%) | jacket | elongation before aging | ≥ 150 % | |||
| 3p:S=14.0mm(24%) | tensile strength before aging | ≥10.5 MPa | ||||
| 4p:S=12.5mm(21%) | elongation after aging | ≥ 125 % | ||||
Inner Assemble | Lay | S=90±5mm | tensile strength after aging | ≥ 10 MPa | ||
| Direction | according to the drawing | Packing | ||||
| Filler | 5.0±0.1mm x 0.5±0.01mm | |||||
| OD | / | Drum | NA | |||
Filler | Material | Ripcord | ||||
| Construction | 300D | |||||
Outside Shield | Shield | / | ||||
| Construction | / | |||||
| Material | / | |||||
| Coverage | / | |||||
Jacket | Material | LSZH | ||||
| Hardness | 81A±3A | |||||
| OD | 7.0±0.5mm | |||||
| Average THK | 0.7mm+Gear | |||||
| Color | Blue | |||||
| Marking Color | according to the customer's requirements | |||||
| Marking | according to the customer's requirements | |||||
| Electrical Properties | ||
| Single Conductor DC Resistance,Max,20℃(Ω/100m) | NF EN 50289 | 9.5 |
| Conductor DC Resistance Imbalance,Max,20℃(%) | ≤2 | |
| Pairs DC Resistance Imbalance,Max,20℃(%) | ≤4 | |
Dielectric Strength Conductor/Conductor:2.5KV DC for 2 seconds or 1KV DC for 1 minute | No Breakdown | |
Insulation Resistance Insulation Resistance(Conductor/Conductor),DC100-500V,Min(MΩ.km) | 5000 | |
| Pair To Ground Capacitance Unbalance,Max,0.8KHz∕1KHz(pF/100m) | 160 | |
| Delay Skew,1-250MHz,Max(ns/100m) | 45 | |
| Velocity of Propagation(%) | 69 | |
| Transmission Performance | |||||||||
Freq | Characteristic Impedance Upper Limit | Characteristic Impedance Lower Limit | RL | ATT | NEXT | PS NEXT | EL FEXT | PS ELFEXT | Propagation Delay |
| MHz | Ω | Ω | dB | dB/100m | dB/100m | dB/100m | dB/100m | dB/100m | ns/100m |
| 4 | 115.2 | 86.8 | ≥23 | ≤3.8 | ≥66.3 | ≥63.3 | ≥56 | ≥53 | ≤552 |
| 8 | 112.6 | 88.8 | ≥24.5 | ≤5.3 | ≥61.8 | ≥58.8 | ≥49.9 | ≥46.9 | ≤547 |
| 10 | 111.9 | 89.4 | ≥25 | ≤5.9 | ≥60.3 | ≥57.3 | ≥48 | ≥45 | ≤545 |
| 16 | 111.9 | 89.4 | ≥25 | ≤7.5 | ≥57.2 | ≥54.2 | ≥43.9 | ≥40.9 | ≤543 |
| 20 | 111.9 | 89.4 | ≥25 | ≤8.4 | ≥55.8 | ≥52.8 | ≥42 | ≥39 | ≤542 |
| 25 | 112.9 | 88.5 | ≥24.3 | ≤9.4 | ≥54.3 | ≥51.3 | ≥40 | ≥37 | ≤541 |
| 31.25 | 114.1 | 87.7 | ≥23.6 | ≤10.5 | ≥52.9 | ≥49.9 | ≥38.1 | ≥35.1 | ≤540 |
| 62.5 | 118.3 | 84.5 | ≥21.5 | ≤15 | ≥48.4 | ≥45.4 | ≥32.1 | ≥29.1 | ≤539 |
| 100 | 121.9 | 82 | ≥20.1 | ≤19.1 | ≥45.3 | ≥42.3 | ≥28 | ≥25 | ≤538 |
| 200 | 128.8 | 77.6 | ≥18 | ≤27.6 | ≥40.8 | ≥37.8 | ≥22 | ≥19 | ≤537 |
| 250 | 131.6 | 76 | ≥17.3 | ≤31.1 | ≥39.3 | ≥36.3 | ≥20 | ≥17 | ≤536 |
| 300 | 133.7 | 74.7 | ≥17.3 | ≤34.3 | ≥38.1 | ≥35.1 | ≥18.5 | ≥15.5 | ≤536 |
| 400 | 138.2 | 72.4 | ≥17.3 | ≤40.1 | ≥36.3 | ≥33.3 | ≥16 | ≥13 | ≤536 |
| 500 | 142 | 70.4 | ≥17.3 | ≤45.3 | ≥34.8 | ≥31.8 | ≥14 | ≥11 | ≤536 |
1.CAT6A UTP 23AWG Bare Solid Copper LSZH CPR B2ca 10Gbps Network Cable 1000FT is well - known for its remarkable high - speed data transfer capabilities. Our cable is no different. With a frequency of 500 MHz, it is an ideal choice for high - bandwidth scenarios like data centers, server farms, and other enterprise - level applications.
2.The blue jacket of our UTP Cat6A Cable, made of LSZH material,
not only gives the cable an appealing look but also provides
enhanced protection. This LSZH jacket is resistant to abrasion,
chemicals, and UV light, making the cable perfect for use in harsh
environments where regular cables might be easily damaged or
degraded. More importantly, in case of a fire, the LSZH feature
ensures that the cable emits little smoke and no halogen gases,
safeguarding both people and equipment. It complies with the CPR
(Construction Products Regulation) with a B2ca rating, meeting
strict European safety and performance standards.
3.Our cable is rated for speeds of up to 10Gbps, making it highly
suitable for high - speed networks that require reliable and fast
data transfer. When connecting servers, switches, or other network
devices, our UTP Cat6A Cable guarantees that your data is
transferred quickly and efficiently.
4.This cable is also excellent for home or office networks. When
you're streaming media, playing online games, or simply browsing
the web, it ensures a fast and reliable network connection. In
addition, in educational institutions such as schools and
universities, this cable can be used to build stable campus
networks. It can handle the large - scale data transmission
required for online teaching, learning management systems, and
library information systems. In hospitals, it can be used to
connect medical equipment, ensuring the stable transmission of
patient data and the reliable operation of diagnostic and
monitoring systems. In industrial environments, such as factories
and manufacturing plants, the cable's durability allows it to
withstand the rigors of the environment, including exposure to
dust, moisture, and mechanical stress, while maintaining stable
data transfer between industrial control systems and automated
machinery.
5.In summary, our CAT6A UTP 23AWG Bare Solid Copper LSZH CPR B2ca
10Gbps Network Cable 1000FT is a high - quality, reliable, and
versatile cable applicable in a wide range of applications. Whether
you're establishing a complex network infrastructure or just
connecting a few devices at home or in the office, this cable will
undoubtedly meet your requirements.
1.Q:What is the maximum transmission distance of the ITI-LINK ITI-C6AU-002 CAT6A cable?
A: The maximum transmission distance of the ITI-LINK ITI-C6AU-002 CAT6A cable is 100 meters.
2. Q: Is the ITI-LINK ITI-C6AU-002 CAT6A cable compatible with 10 Gigabit Ethernet?
A: Yes, the ITI-LINK ITI-C6AU-002 CAT6A cable is fully compatible with 10 Gigabit Ethernet.
3. Q: What is the diameter of the ITI-LINK ITI-C6AU-002 CAT6A cable?
A: The diameter of the ITI-LINK ITI-C6AU-002 CAT6A cable is 6mm.
A: The jacket material of the ITI-LINK ITI-C6AU-002 CAT6A cable is LSZH.
A: The ITI-LINK ITI-C6AU-002 CAT6A cable is manufactured in SHENZHEN.
|
|
