Cat5e UTP LSZH 24AWG Solid bare copper Network Cable 1000FT
Description:
This high-performance Low Smoke Zero Halogen (LSZH) Category 5e Ethernet cable is designed specifically for modern high-speed network applications. Using advanced low smoke and halogen-free materials, this network cable not only ensures high-speed and stable data transmission, but also greatly improves safety and environmental performance.
1. Low Smoke Zero Halogen: The unique LSZH (Low Smoke Zero Halogen) material releases very little smoke during combustion and does not contain harmful substances such as halogens, effectively reducing harm to the environment and human health. It is particularly suitable for places with extremely high safety requirements, such as data centers, office buildings, hospitals, and schools.
2. High quality copper core: using high-purity oxygen free copper conductors to ensure extremely low signal transmission loss, supporting Ethernet transmission speeds up to 100Mbps, easily meeting various high-speed data transmission needs.
3. Durable outer layer: covered with high-quality PVC sheath to enhance the wear resistance and tear resistance of the cable, while maintaining its flexibility and ease of wiring, extending its service life.
> Category: Cat5e UTP LSZH CABLE
> Transmission rate: 100Mbps Ethernet and higher (up to 1Gbps under ideal conditions)
> Frequency bandwidth: 100MHz
> Impedance: 100 Ω
> Transmission distance: up to 100 meters (compliant with Ethernet standards)
> Color selection: Multiple colors available for easy differentiation and management
of different routes
> RoHs/REACH Complied LSZH Jacket
> Rate temperature:60℃ 75℃
> InstallationTemperature: -30℃-+50℃
> CompliestoANSI/TIA-568-B.2&IS0/EC11801
> CE, RoHS, TUV, UL compliant, CPR, ETL, RCM, ISO9001
Specifications:
| Product Description: Cat 5e UTP 4 X 2 X 24AWG LSZH | ||||||
| Rev.: A | ECN Description: | |||||
| Construction Item Description | Electrical Property | |||||
Conductor | Material | Bare Solid Copper(elongation: 19 ~ 24%) | Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m | ||
| OD | 24 AWG | Resistance unbalance within a pair | ≤ 2% | |||
Insulation | Material | HDPE 8303 | Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | >1500 MΩ / 100m | ||
| OD | 0.90 ± 0.01 mm | Mutual capacitance | 5600 pF / 100m MAX | |||
| Average THK | 0.20 mm | Capacitance unbalance pair to ground at 800Hz or 1 kHz | ≤ 160 pF / 100m | |||
Color | 1p: white + 2 blue stripes & blue | Characteristic impedance at 100MHz | 100 ± 15 Ω | |||
| 2p: white + 2 orange stripes & orange | Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | No breakdown | ||||
| 3p: white + 2 green stripes & green | Mechanical Property | |||||
| 4p: white + 2 brown stripes & brown | insulation | elongation before aging | ≥ 300% | |||
Pair Twist | Lay & Direction | 1p: S=20.0 mm (28%) | tensile strength before aging | ≥12 MPa | ||
| 2p: S=17.5 mm (24%)) | elongation after aging | ≥ 150 % | ||||
| 3p: S=22.0 mm (32%) | tensile strength after aging | ≥10.5 MPa | ||||
| 4p: S=15.5 mm (21%) | jacket | elongation before aging | ≥ 150 % | |||
| OD | / | tensile strength before aging | ≥ 13.5 MPa | |||
Inner Assemble | Lay | S=90 ± 5 mm | elongation after aging | ≥ 125 % | ||
| Direction | according to the drawing | tensile strength after aging | ≥ 12.5 MPa | |||
| Filler | / | Packing | ||||
| OD | / | Inner Box | NA | |||
| Filler | Material | Ripcord | Master Carton | NA | ||
| Construction | 300D | |||||
Outside Shield | Shield | / | ||||
| Construction | / | |||||
| Material | / | |||||
| Coverage | / | |||||
Jacket | Material | LSZH, 60P, -20~75℃ | ||||
| Hardness | 81 ± 3 | |||||
| OD | 4.8 ± 0.15 | |||||
| Average THK | 0.30 ~ 0.40 | |||||
Color | according to the customer's requirements | |||||
| Marking Color | black | |||||
| Marking | according to the customer's requirements | |||||
| Electrical Properties | ||
| Conductor Resistance at 20°C | NF EN 50289-1-2 / IEC 60189-1 | ≤ 9.5 Ω / 100m |
| Resistance unbalance within a pair | NF EN 50289-1-2/ IEC 60708 | ≤ 2% |
Dielectric Strength Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | NF EN 50289-1-3 / IEC 61196-1-105 | No breakdown |
| Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | NF EN 50289-1-4 / IEC 60885-1 | >1500 MΩ / 100m |
| Mutual capacitance | NF EN 50289-1-5 /IEC 60189-1 | 5600pF / 100m MAX |
| Capacitance unbalance pair to ground at 800Hz or 1 kHz | NF EN 50289-1-5 / IEC 60189-1 | ≤ 160 pF / 100m |
| Characteristic impedance at 100MHz | NF EN 50289-1-11/ IEC 61156-1 | 100 ± 15 Ω |
| Spark Test | UL444 | 2000 ± 250VOC |
| Transmission Properties | |||||||||
| CAT5e ANSI/TIA-568.2-D; IEC 61156-6; YD/T1019-2013 | |||||||||
No. | Frequency | Attenuation (Max) | Propagation Delay (MAX) | Propagation Delay Skew (MAX) | Return Loss (Min) | NEXT (Min) | PS NEXT (Min) | EL-FEXT (Min) | PS EL-FEXT (Min) |
| MHz | dB/100m | ns/100m | ns/100m | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | |
| 1 | 4 | 4.05 | 552 | 45 | 23.01 | 56.27 | 53.27 | 51.96 | 48.96 |
| 2 | 8 | 5.77 | 546.73 | 45 | 24.52 | 51.75 | 48.75 | 45.94 | 42.94 |
| 3 | 10 | 6.47 | 545.38 | 45 | 25 | 50.3 | 47.3 | 44 | 41 |
| 4 | 16 | 8.25 | 543 | 45 | 25 | 47.24 | 44.24 | 39.92 | 36.92 |
| 5 | 20 | 9.27 | 542.05 | 45 | 25 | 45.78 | 42.78 | 37.98 | 34.98 |
| 6 | 25 | 10.42 | 541.2 | 45 | 24.32 | 44.33 | 41.33 | 36.04 | 33.04 |
| 7 | 31.25 | 11.72 | 540.44 | 45 | 23.64 | 42.88 | 39.88 | 34.1 | 31.1 |
| 8 | 50 | 15.07 | 539.09 | 45 | 22.21 | 39.82 | 36.82 | 30.02 | 27.02 |
| 9 | 62.5 | 16.99 | 538.55 | 45 | 21.54 | 38.36 | 35.36 | 28.08 | 25.08 |
| 10 | 100 | 21.98 | 537.6 | 45 | 20.11 | 35.3 | 32.3 | 24 | 21 |
| 11 | |||||||||
| 12 | |||||||||
| 13 | |||||||||
| 14 | |||||||||
| Remarks: ＊ are the reference values | |||||||||
Notices:
1. Open the packaging, check the products carefully, and take them gently.
2. Please strictly follow the wiring standards during construction, and do not tie or excessively bend the network cables.
3. When making RJ45 network cable connectors, please follow the T568B or T568A standards to ensure the correct wire sequence and avoid problems such as disconnected lines or unstable network connections.
4.It is best to use a single network cable at a distance of no more than 100 meters to ensure optimal transmission performance.
5. Ensure that the shielded network cable is grounded during installation.
Applications:
1. LSZH Cat5e Ethernet cable, with their unique environmental and safety features, are widely used in multiple key fields and scenarios, ensuring efficient and secure data transmission.
2. In modern office environments, this Cat5e cable has become the cornerstone of building high-speed LANs. Whether it is busy commercial buildings or government agencies that prioritize efficiency and safety, LSZH Category 5e Ethernet cables can provide stable data transmission, support efficient office processes and file sharing. At the same time, their low smoke and halogen-free characteristics can significantly reduce the harm of smoke in emergency situations and ensure the safe evacuation of personnel.
3. Safety and reliability are crucial in medical facilities. LSZH Cat5e cable not only supports high-speed data transmission between medical devices such as medical imaging and electronic medical record systems, but also meets the high air quality requirements of medical facilities through the application of environmentally friendly materials, creating a safer and healthier treatment environment for patients and medical staff.
4. Educational institutions also benefit from the application of this network cable. In the school network, LSZH Category 5e Ethernet not only supports stable operation of multimedia teaching and online learning platforms, but also helps maintain the green ecology of the campus due to its environmental characteristics, creating a safer and healthier learning environment for students.
5. In addition, LSZH Category 5e Ethernet cables also play an indispensable role in data centers, monitoring systems, and smart homes. It can not only meet the demand for high-speed data transmission, but also provide additional security guarantees in emergency situations, reducing the impact of smoke on equipment and personnel.
