CAT6 SFTP Ethernet Cable PVC Jacket Copper Conductor for High-Speed Data Transfer
Product Description:
1.The CAT6 SFTP Ethernet Cable is a paragon of networking excellence, meticulously crafted to satisfy the exacting demands of modern network ecosystems. Boasting an array of high - end features, it emerges as an optimal solution for both residential and commercial networking requirements.
2.Central to its appeal is the cable’s sturdily built structure. The cable features 23AWG copper conductors. The thickness of these conductors—at 23AWG—ensures stable data transmission and pristine signal integrity. The employment of top - tier copper as the conductor material further amplifies the cable’s performance, rendering it eminently suitable for high - speed, bandwidth - intensive applications.
3.Equipped with a remarkable maximum data rate of 10Gbps, the CAT6 SFTP Ethernet Cable can effortlessly shoulder high - bandwidth loads. Whether you're streaming high - resolution media, executing large - scale file transfers, or competing in online gaming tournaments, this cable guarantees a seamless, latency - free experience.
4.The cable's exterior is sheathed in a durable blue PVC jacket. This jacket provides not only protection against external threats like moisture, dust, and mechanical impact but also simplifies cable identification in complex networking setups. The resilience of the PVC jacket significantly extends the cable’s lifespan, making it a reliable long - term investment.
5.Moreover, this CAT6 SFTP Ethernet Cable offers reliable connectivity over an extended range. Even at a distance of up to 100 meters, it can maintain consistent performance, making it suitable for a wide range of networking scenarios—from large - scale office complexes to data centers and residential spaces.
6.Whether you're embarking on a new network installation or seeking to enhance an existing one, the CAT6 SFTP Ethernet Cable offers unrivaled performance and reliability. Its combination of high - quality materials, advanced design, and outstanding transmission capabilities cements its position as an indispensable element of any modern networking infrastructure. Enjoy seamless connectivity and rapid data transfer with this premium - grade CAT6 Ethernet cable.
Technical Parameters:
| Cable Type | CAT6 SFTP Cable |
| Maximum Frequency | 250MHz |
| Shielding Type | SFTP |
| Maximum Data Rate | 1Gbps |
| Conductor Material | Copper |
| Jacket Material | PVC |
| Conductor Size | 23AWG |
| Product Description: CAT6 SFTP Ethernet Cable PVC Jacket Copper Conductor for High-Speed Data Transfer | ||||||
| Rev.: A | ECN Description: | |||||
| Construction Item Description | Electrical Property | |||||
Conductor | Material | Bare Solid Copper(elongation: 19-24%) | Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m | ||
| OD | 23 AWG | Resistance unbalance within a pair | ≤ 2% | |||
Insulation | Material | HDPE | Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | >1500 MΩ / 100m | ||
| OD | 1.14 ±0.05 mm | Mutual capacitance | 5600 pF / 100m MAX | |||
| Average THK | 0.24 mm | Capacitance unbalance pair to ground at 800Hz or 1 kHz | ≤ 160 pF / 100m | |||
Color | 1p: white + 2 blue stripes & blue | Characteristic impedance at 100MHz | 100 ± 15 Ω | |||
| 2p: white + 2 orange stripes & orange | Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | No breakdown | ||||
| 3p: white + 2 green stripes & green | Mechanical Property | |||||
| 4p: white + 2 brown stripes & brown | insulation | elongation before aging | ≥ 300% | |||
Pair Twist | Lay & Direction | 1p: S=19.0 mm (27%) | tensile strength before aging | ≥12 MPa | ||
| 2p: S=23.5 mm (35%) | elongation after aging | ≥ 150 % | ||||
| 3p: S=21.5 mm (31%) | tensile strength after aging | ≥10.5 MPa | ||||
| 4p: S=27.0 mm (40%) | jacket | elongation before aging | ≥ 150 % | |||
| OD | / | tensile strength before aging | ≥ 13.5 MPa | |||
Inner Assemble | Lay | S=90 ± 5 mm | elongation after aging | ≥ 125 % | ||
| Direction | according to the drawing | tensile strength after aging | ≥ 12.5 MPa | |||
| Filler | cross member 5.0X5.0X0.5mmT | Packing | ||||
| OD | / | NA | NA | |||
| Filler | Ripcord | 300D | ||||
| Drain Wire | Tinned Copper | |||||
Shield | Shield | Shield | ||||
| Construction | / | |||||
| Material | Polyester/Aluminium (PET/ALU) | |||||
| Coverage | ≥ 115% | |||||
Jacket | Material | PVC, 50P, -20~75℃ | ||||
| Hardness | 81± 3 | |||||
| OD | 7.2 ± 0.2 | |||||
| Average THK | 0.55 ~ 0.60 | |||||
Color | Blue | |||||
| Marking Color | according to the customer's requirements | |||||
| Marking | according to the customer's requirements | |||||
| Transmission Properties | |||||||||
| CAT 6 ANSI/TIA-568.2-D; IEC 61156-6; YD/T1019-2013 | |||||||||
No. | Frequency | Attenuation (Max) | Propagation Delay (MAX) | Propagation Delay Skew (MAX) | Return Loss (Min) | NEXT (Min) | PS NEXT (Min) | EL-FEXT (Min) | PS EL-FEXT (Min) |
| MHz | dB/100m | ns/100m | ns/100m | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | |
| 1 | 4 | 3.78 | 552 | 45 | 23.01 | 66.27 | 63.27 | 55.96 | 52.96 |
| 2 | 8 | 5.32 | 546.73 | 45 | 24.52 | 61.75 | 58.75 | 49.94 | 46.94 |
| 3 | 10 | 5.95 | 545.38 | 45 | 25 | 60.3 | 57.3 | 48 | 45 |
| 4 | 16 | 7.55 | 543 | 45 | 25 | 57.24 | 54.24 | 43.92 | 40.92 |
| 5 | 20 | 8.47 | 542.05 | 45 | 25 | 55.78 | 52.78 | 41.98 | 38.98 |
| 6 | 25 | 9.51 | 541.2 | 45 | 24.32 | 54.33 | 51.33 | 40.04 | 37.04 |
| 7 | 31.25 | 10.67 | 540.44 | 45 | 23.64 | 52.88 | 49.88 | 38.1 | 35.1 |
| 8 | 50 | 13.66 | 539.09 | 45 | 22.21 | 49.82 | 46.82 | 34.02 | 31.02 |
| 9 | 62.5 | 15.38 | 538.55 | 45 | 21.54 | 48.36 | 45.36 | 32.08 | 29.08 |
| 10 | 100 | 19.8 | 537.6 | 45 | 20.11 | 45.3 | 42.3 | 28 | 25 |
| 11 | 125 | 22.36 | 537.22 | 45 | 19.43 | 43.85 | 40.85 | 26.06 | 23.06 |
| 12 | 200 | 28.98 | 536.55 | 45 | 18 | 40.78 | 37.78 | 21.98 | 18.98 |
| 13 | 250 | 32.85 | 536.28 | 45 | 17.32 | 39.33 | 36.33 | 20.04 | 17.04 |
| 14 | |||||||||
| 15 | |||||||||
| 16 | |||||||||
| 17 | |||||||||
| 18 | |||||||||
| Remarks: ＊ are the reference values. | |||||||||
| Electrical Properties | ||
| Conductor Resistance at 20°C | NF EN 50289-1-2 / IEC 60189-1 | ≤ 9.5 Ω / 100m |
| Resistance unbalance within a pair | NF EN 50289-1-2/ IEC 60708 | ≤ 2% |
Dielectric Strength Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | NF EN 50289-1-3 / IEC 61196-1-105 | No breakdown |
| Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | NF EN 50289-1-4 / IEC 60885-1 | >1500 MΩ / 100m |
| Mutual capacitance | NF EN 50289-1-5 /IEC 60189-1 | 5600pF / 100m MAX |
| Capacitance unbalance pair to ground at 800Hz or 1 kHz | NF EN 50289-1-5 / IEC 60189-1 | ≤ 160 pF / 100m |
| Characteristic impedance at 100MHz | NF EN 50289-1-11/ IEC 61156-1 | 100 ± 15 Ω |
| Spark Test | UL444 | 2000 ± 250VOC |
Applications:
1.The CAT6 SFTP Ethernet Cable represents a pinnacle of networking technology. Engineered in Shenzhen, this high - end cable is constructed with the precision and quality demanded by modern networking environments.
2.The cable’s exterior features a durable blue PVC jacket. This jacket not only provides protection against external elements like moisture, dust, and physical stress but also simplifies cable identification in complex network setups. Inside, 23AWG copper conductors, combined with advanced shielding technology, ensure maximum signal integrity over long distances. With a maximum transmission range of 100 meters, it meets the needs of both small - scale and large - scale installations.
3.Thanks to its robust construction and use of top - grade materials, the CAT6 SFTP Ethernet Cable is suitable for a wide variety of scenarios. Whether you're building a high - performance small - office network, connecting multiple devices in a home entertainment system, or equipping a commercial space with a high - speed internet connection, this cable can handle the job with ease.
3.The cable supports a maximum frequency of 250MHz and data rates of up to 10Gbps. This makes it perfect for bandwidth - intensive applications such as real - time 4K video streaming, large - volume file transfers, and online gaming. It ensures stable and high - speed data transfer, minimizing latency and signal interference.
4.For professional network installers seeking a reliable product for their projects, tech enthusiasts aiming to enhance their home networks, or business owners in search of high - performance networking solutions, the CAT6 SFTP Ethernet Cable (SF-CT6SF-B) is an excellent, all - around choice. Count on its top - tier quality and unrivaled performance to meet all your networking requirements.
FAQ:
Q: What is the brand of this SFTP CAT6 Cable?
A: The brand of this cable is ITI-LINK.
Q: What is the model number of this SFTP CAT6 Cable?
A: The model number of this cable is ITI-CT6SF-06.
Q: Where is this SFTP CAT6 Cable manufactured?
A: This cable is manufactured in SHENZHEN.
Q: What is the maximum data transfer speed supported by this SFTP CAT6 Cable?
A: This cable supports data transfer speeds of up to 1 Gigabit per second.
Q: Is this SFTP CAT6 Cable suitable for outdoor use?
A: Yes, this cable is designed for both indoor and outdoor use, providing reliable performance in various environments.
|
|
