SFTP CAT6 Ethernet Cable 23AWG Conductor for Maximum Transmission Distance up to 100m
Product Description:
1.ITI-LINK proudly presents the ITI-CT6SF-09 SFTP CAT6 Ethernet Cable. Engineered in pursuit of top - tier networking performance, this cable is meticulously designed to meet diverse data transmission requirements.
2.The ITI-CT6SF-09 features a 23AWG conductor. This conductor size, combined with high - purity copper material, ensures outstanding signal conductivity and minimal signal loss. As a result, it enables reliable data transmission over extended distances, reaching up to 100 meters.
3.Wrapped in a blue Low Smoke Zero Halogen (LZSH) jacket, the cable not only offers excellent protection to its internal components but also contributes to a safer networking environment. The blue LZSH jacket is highly durable, resistant to abrasion, moisture, and various environmental factors. This makes the cable suitable for both indoor and outdoor installations. Additionally, the distinct blue color simplifies cable identification in complex wiring setups.
4.Equipped with Shielded Foiled Twisted Pair (SFTP) technology, the ITI-CT6SF-09 effectively guards against electromagnetic interference (EMI) and radio frequency interference (RFI). This ensures stable and secure data transmission, even in environments rife with interference and crosstalk. Whether it's a bustling office space or a high - tech data center, this cable maintains consistent performance.
5.Capable of supporting a maximum data rate of 10Gbps, the ITI-CT6SF-09 is perfectly suited for bandwidth - intensive applications. From seamless 4K video streaming to rapid large - file transfers and latency - sensitive online gaming, it delivers the speed and reliability users expect.
6.Whether you're establishing a small office network, upgrading a home entertainment system, or building a large - scale data center, the ITI-CT6SF-09 SFTP CAT6 Ethernet Cable is an incredibly versatile and reliable choice.
7.Choose the ITI-LINK ITI-CT6SF-09 to upgrade your network infrastructure. Experience seamless connectivity, rapid data transmission, and unwavering reliability. It’s a worthy investment in a high - quality networking solution that keeps pace with the demands of modern networking environments.
Technical Parameters:
| Cable Type | CAT6 SFTP Cable |
| Maximum Frequency | 250MHz |
| Shielding Type | SFTP |
| Maximum Data Rate | 10 Gbps |
| Conductor Material | Copper |
| Jacket Material | LSZH |
| Conductor Size | 23AWG |
| Product Description: Data Transfer SFTP CAT6 Cable with LSZH Jacket Material and 250MHz Maximum Frequency | ||||||
| Rev.: A | ECN Description: | |||||
| Construction Item Description | Electrical Property | |||||
Conductor | Material | Bare Solid Copper(elongation: 19-24%) | Conductor Resistance at 20°C | ≤ 9.5 Ω / 100m | ||
| OD | 23 AWG | Resistance unbalance within a pair | ≤ 2% | |||
Insulation | Material | HDPE | Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | >1500 MΩ / 100m | ||
| OD | 1.14 ±0.05 mm | Mutual capacitance | 5600 pF / 100m MAX | |||
| Average THK | 0.24 mm | Capacitance unbalance pair to ground at 800Hz or 1 kHz | ≤ 160 pF / 100m | |||
Color | 1p: white + 2 blue stripes & blue | Characteristic impedance at 100MHz | 100 ± 15 Ω | |||
| 2p: white + 2 orange stripes & orange | Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | No breakdown | ||||
| 3p: white + 2 green stripes & green | Mechanical Property | |||||
| 4p: white + 2 brown stripes & brown | insulation | elongation before aging | ≥ 300% | |||
Pair Twist | Lay & Direction | 1p: S=19.0 mm (27%) | tensile strength before aging | ≥12 MPa | ||
| 2p: S=23.5 mm (35%) | elongation after aging | ≥ 150 % | ||||
| 3p: S=21.5 mm (31%) | tensile strength after aging | ≥10.5 MPa | ||||
| 4p: S=27.0 mm (40%) | jacket | elongation before aging | ≥ 150 % | |||
| OD | / | tensile strength before aging | ≥ 13.5 MPa | |||
Inner Assemble | Lay | S=90 ± 5 mm | elongation after aging | ≥ 125 % | ||
| Direction | according to the drawing | tensile strength after aging | ≥ 12.5 MPa | |||
| Filler | cross member 5.0X5.0X0.5mmT | Packing | ||||
| OD | / | NA | NA | |||
| Filler | Ripcord | 300D | ||||
| Drain Wire | Tinned Copper | |||||
Shield | Shield | Shield | ||||
| Construction | / | |||||
| Material | Polyester/Aluminium (PET/ALU) | |||||
| Coverage | ≥ 115% | |||||
Jacket | Material | LSZH, 60P, -20~75℃ | ||||
| Hardness | 81± 3 | |||||
| OD | 7.2 ± 0.2 | |||||
| Average THK | 0.55 ~ 0.60 | |||||
Color | Yellow | |||||
| Marking Color | according to the customer's requirements | |||||
| Marking | according to the customer's requirements | |||||
| Transmission Properties | |||||||||
| CAT 6 ANSI/TIA-568.2-D; IEC 61156-6; YD/T1019-2013 | |||||||||
No. | Frequency | Attenuation (Max) | Propagation Delay (MAX) | Propagation Delay Skew (MAX) | Return Loss (Min) | NEXT (Min) | PS NEXT (Min) | EL-FEXT (Min) | PS EL-FEXT (Min) |
| MHz | dB/100m | ns/100m | ns/100m | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | dB(on 100m) | |
| 1 | 4 | 3.78 | 552 | 45 | 23.01 | 66.27 | 63.27 | 55.96 | 52.96 |
| 2 | 8 | 5.32 | 546.73 | 45 | 24.52 | 61.75 | 58.75 | 49.94 | 46.94 |
| 3 | 10 | 5.95 | 545.38 | 45 | 25 | 60.3 | 57.3 | 48 | 45 |
| 4 | 16 | 7.55 | 543 | 45 | 25 | 57.24 | 54.24 | 43.92 | 40.92 |
| 5 | 20 | 8.47 | 542.05 | 45 | 25 | 55.78 | 52.78 | 41.98 | 38.98 |
| 6 | 25 | 9.51 | 541.2 | 45 | 24.32 | 54.33 | 51.33 | 40.04 | 37.04 |
| 7 | 31.25 | 10.67 | 540.44 | 45 | 23.64 | 52.88 | 49.88 | 38.1 | 35.1 |
| 8 | 50 | 13.66 | 539.09 | 45 | 22.21 | 49.82 | 46.82 | 34.02 | 31.02 |
| 9 | 62.5 | 15.38 | 538.55 | 45 | 21.54 | 48.36 | 45.36 | 32.08 | 29.08 |
| 10 | 100 | 19.8 | 537.6 | 45 | 20.11 | 45.3 | 42.3 | 28 | 25 |
| 11 | 125 | 22.36 | 537.22 | 45 | 19.43 | 43.85 | 40.85 | 26.06 | 23.06 |
| 12 | 200 | 28.98 | 536.55 | 45 | 18 | 40.78 | 37.78 | 21.98 | 18.98 |
| 13 | 250 | 32.85 | 536.28 | 45 | 17.32 | 39.33 | 36.33 | 20.04 | 17.04 |
| 14 | |||||||||
| 15 | |||||||||
| 16 | |||||||||
| 17 | |||||||||
| 18 | |||||||||
| Remarks: ＊ are the reference values. | |||||||||
| Electrical Properties | ||
| Conductor Resistance at 20°C | NF EN 50289-1-2 / IEC 60189-1 | ≤ 9.5 Ω / 100m |
| Resistance unbalance within a pair | NF EN 50289-1-2/ IEC 60708 | ≤ 2% |
Dielectric Strength Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min | NF EN 50289-1-3 / IEC 61196-1-105 | No breakdown |
| Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V | NF EN 50289-1-4 / IEC 60885-1 | >1500 MΩ / 100m |
| Mutual capacitance | NF EN 50289-1-5 /IEC 60189-1 | 5600pF / 100m MAX |
| Capacitance unbalance pair to ground at 800Hz or 1 kHz | NF EN 50289-1-5 / IEC 60189-1 | ≤ 160 pF / 100m |
| Characteristic impedance at 100MHz | NF EN 50289-1-11/ IEC 61156-1 | 100 ± 15 Ω |
| Spark Test | UL444 | 2000 ± 250VOC |
Applications:
1.ITI-LINK proudly presents the ITI-CT6SF-09 SFTP CAT6 Ethernet Cable, a top-notch networking solution meticulously engineered for diverse applications and scenarios.
2.Crafted in SHENZHEN, this cable is built to last, featuring 23AWG copper conductors that ensure outstanding conductivity and rock-solid signal stability. The 23AWG conductor size strikes an optimal balance, enabling efficient data transfer while maintaining the cable's flexibility for easy installation.
3.Wrapped in a blue Low Smoke Zero Halogen (LZSH) jacket, the ITI-CT6SF-09 not only offers superior protection to its internal components against abrasion, moisture, and environmental factors but also enhances safety during installation. The distinct blue color simplifies cable identification in complex wiring setups, saving time and effort.
4.Thanks to its SFTP (Shielded Foiled Twisted Pair) design, this cable provides robust defense against electromagnetic interference, making it an excellent choice for environments where signal integrity is of utmost importance, such as data centers, industrial settings, or areas with high electromagnetic activity.
5.Whether you're establishing a small office network, setting up a data center, or upgrading your residential Ethernet connection, the ITI-CT6SF-09 is a versatile and reliable option. It can support data transmission at speeds of up to 250MHz, effortlessly meeting the demands of modern networking applications, from seamless 4K video streaming to high-latency-sensitive online gaming.
6.With a maximum transmission distance of up to 100 meters, this cable is suitable for both short and medium-length network connections. It's the perfect fit for linking computers, routers, switches, IP cameras, and other network devices, ensuring smooth and stable data flow.
7.Whether you're a professional network installer seeking a dependable cable for projects, an IT technician in need of a high-performance solution, or a home user aiming to enhance your network infrastructure, the ITI-LINK ITI-CT6SF-09 SFTP CAT6 Ethernet Cable offers a reliable and cost-effective choice. Place your trust in the quality and performance of ITI-LINK products to fulfill all your networking needs.
FAQ:
Q: What is the brand of this SFTP CAT6 Cable?
A: The brand of this cable is ITI-LINK.
Q: What is the model number of this SFTP CAT6 Cable?
A: The model number of this cable is ITI-CT6SF-09.
Q: Where is this SFTP CAT6 Cable manufactured?
A: This cable is manufactured in SHENZHEN.
Q: What is the maximum data transfer speed supported by this SFTP CAT6 Cable?
A: This cable supports data transfer speeds of up to 1 Gigabit per second.
Q: Is this SFTP CAT6 Cable suitable for outdoor installations?
A: Yes, this cable is designed for both indoor and outdoor installations, providing weatherproof and UV-resistant properties.
|
|
