Cat8 SFTP Shielded Ethernet Cable 2000MHz 40Gbps 22AWG Pure Copper for Network

Integrity Cable Co., Limited
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Cat8 SFTP Shielded Ethernet Cable 2000MHz 40Gbps 22AWG Pure Copper for Network from wholesalers

    Buy cheap Cat8 SFTP Shielded Ethernet Cable 2000MHz 40Gbps 22AWG Pure Copper for Network from wholesalers
    • Buy cheap Cat8 SFTP Shielded Ethernet Cable 2000MHz 40Gbps 22AWG Pure Copper for Network from wholesalers
    • Buy cheap Cat8 SFTP Shielded Ethernet Cable 2000MHz 40Gbps 22AWG Pure Copper for Network from wholesalers
    • Buy cheap Cat8 SFTP Shielded Ethernet Cable 2000MHz 40Gbps 22AWG Pure Copper for Network from wholesalers

    Cat8 SFTP Shielded Ethernet Cable 2000MHz 40Gbps 22AWG Pure Copper for Network

    Ask Lasest Price
    Brand Name : ITI-LINK
    Model Number : ITI-CTSF8-006
    Certification : UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
    Payment Terms : T/T
    Supply Ability : 2000pcs/day
    Delivery Time : 15-45 Days
    • Product Details
    • Company Profile

    Cat8 SFTP Shielded Ethernet Cable 2000MHz 40Gbps 22AWG Pure Copper for Network

    Cat8 SFTP Shielded Ethernet Cable 2000MHz 40Gbps 26AWG Pure Copper for Network


    Product Description:


    1.The Cat8 SFTP Shielded Ethernet Yellow Cable is a high - end networking cable meticulously crafted to fulfill the stringent demands of contemporary network setups. Sporting a frequency rating of 2000 MHz and a remarkable data transfer speed of 40Gbps, this cable is a powerhouse for ensuring rapid data transmission and unwavering connectivity within your network infrastructure.


    2.Constructed with 22AWG pure copper conductors, the Cat8 cable showcases exceptional conductivity. The relatively thicker 22AWG pure copper conductors are highly effective in minimizing signal loss, which is crucial for maintaining efficient data transfer even over extended distances. The utilization of pure copper as the conductor material not only guarantees durability but also provides the stability required for seamless network operations, making this cable an excellent fit for both residential and commercial network applications.


    3.Featuring a vibrant yellow color, the cable is not only visually distinct but also easier to identify and manage within a network. Encased in a durable PVC jacket, it offers enhanced protection against physical damage, abrasion, and environmental factors. The PVC jacket also provides the flexibility necessary for straightforward installation in various networking scenarios.


    4.With a generous length of 305 meters, the Cat8 SFTP Shielded Ethernet Yellow Cable offers extensive coverage, which is especially beneficial for large - scale network installations. This length significantly reduces the need for additional splicing or intermediate connections, streamlining the network deployment process. Whether you're in the process of establishing a brand - new network from the ground up or enhancing an existing one, this cable provides the flexibility and reach essential to meet all your networking requirements.


    5.As a Category 8 cable, it is engineered specifically to handle high - speed data transmission and meet substantial bandwidth demands. It also boasts backward compatibility with earlier cable categories such as CAT6 and CAT6a. This compatibility ensures that the Cat8 cable can be integrated seamlessly into a wide array of network setups, working harmoniously with diverse network devices.


    6.Whether you're a home user looking to enjoy lag - free 4K streaming and online gaming, a small business owner aiming to boost office productivity with fast and reliable network access, or a network administrator overseeing a complex enterprise - level infrastructure, the Cat8 SFTP Shielded Ethernet Yellow Cable delivers the performance and reliability you need. Its advanced construction, high - performance specifications, and unique features make it an optimal choice for even the most demanding networking environments.


    7.Upgrade your network with the Cat8 SFTP Shielded Ethernet Yellow Cable and experience the advantages of lightning - fast data speeds, enhanced signal integrity, and an overall improvement in network performance. Invest in this top - quality Cat8 LAN Cable, and rest assured that it will continue to support your networking needs, both now and well into the future.


    Technical Parameters:


    Length

    305 Meters

    Conductor Size

    23 AWG

    Jacket Color

    Yellow

    Conductor Material

    Copper

    Frequency

    2000 MHz

    Cable Type

    SFTP

    Jacket Material

    PVC

    Category

    CAT8


    Product Description:Cat8 SFTP Shielded Ethernet Cable 2000MHz 40Gbps 22AWG Pure Copper for Network
    Rev.: AECN Description:
    Construction Item DescriptionElectrical Property

    Conductor


    Material

    Bare Solid Copper(elongation:

    19-24%)

    Conductor Resistance at 20°C≤ 5.6 Ω / 100m
    OD22 AWGResistance unbalance within a pair≤ 0.2%

    Insulation

    MaterialPE Skin-Foam-SkinInsulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V

    >1500 MΩ / 100m

    OD1.62 ±0.01 mmMutual capacitance5600 pF / 100m MAX
    Average THK0.50 mmCapacitance unbalance pair to ground at 800Hz or 1 kHz≤ 160 pF / 100m

    Color

    1p: white + 2 blue stripes & blueCharacteristic impedance at 100MHz100 ± 15 Ω

    2p: white + 2 orange stripes &

    orange

    Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or

    0.7 KV AC for 1 min


    No breakdown

    3p: white + 2 green stripes & greenMechanical Property
    4p: white + 2 brown stripes & brown

    insulation

    elongation before aging≥ 200%

    Pair Twist


    Lay & Direction

    1p: S=19.0 mm (28%)tensile strength before aging≥10 MPa
    2p: S=23.5 mm (31%)elongation after aging≥ 150%
    3p: S=21.5 mm (33%)tensile strength after aging≥8 MPa
    4p: S=25.0 mm (36%)

    jacket

    elongation before aging≥ 150 %
    OD/tensile strength before aging≥ 13.5 MPa

    Inner Assemble

    LayS=90 ± 5 mmelongation after aging≥ 125 %
    Directionaccording to the drawingtensile strength after aging≥ 12.5 MPa
    OD/Packing

    Filler

    Ripcord/NANA
    Drain Wire/

    Pair Shield

    ShieldPair Shield
    Construction/
    MaterialPolyester/Aluminium (PET/ALU)
    Coverage≥ 200%

    Braid

    MaterialAL-MG
    Coverage≥ 40%

    Jacket

    MaterialPVC, 50P, -20~75℃
    Hardness81± 3
    OD8.6 ± 0.2
    Average THK0.65

    Color

    according to the customer's requirements
    Marking ColorYellow
    Marking

    according to the customer's

    requirements



    Electrical Properties
    Conductor Resistance at 20°CNF EN 50289-1-2 / IEC 60189-1≤ 5.6 Ω / 100m
    Resistance unbalance within a pairNF EN 50289-1-2/ IEC 60708≤ 0.2%

    Dielectric Strength

    Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min


    NF EN 50289-1-3 / IEC 61196-1-105


    No breakdown

    Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V

    NF EN 50289-1-4 / IEC 60885-1

    >1500 MΩ / 100m
    Mutual capacitanceNF EN 50289-1-5 /IEC 60189-15600pF / 100m MAX
    Capacitance unbalance pair to ground at 800Hz or 1 kHzNF EN 50289-1-5 / IEC 60189-1≤ 160 pF / 100m
    Characteristic impedance at 100MHzNF EN 50289-1-11/ IEC 61156-1100 ± 15 Ω
    Spark TestUL4442000 ± 250VOC

    Applications:


    1.ITI-Link's Cat8 SFTP Shielded Ethernet Yellow Cable is a top - tier networking cable engineered for a wide array of applications spanning multiple industries. Hailing from Shenzhen, this Cat8 LAN Cable has gained a reputation for its outstanding performance and unwavering reliability.


    2.This yellow - jacketed Cat8 cable, with its unique design, is tailor - made for scenarios demanding ultra - high - speed data transmission and near - zero interference. The 22AWG pure copper conductor size of the cable enables highly efficient data transfer. This makes it an ideal fit for data centers, where large - scale data processing and rapid transfer are the norm, server rooms that require stable and fast connections to support critical operations, and other networking environments where top - notch performance is non - negotiable.


    3.The vibrant yellow jacket of the Cat8 Ethernet Cable serves a dual purpose. It not only imparts a distinct visual identity but also simplifies the identification and management of cables within intricate networking setups. Its SFTP (Shielded Foiled Twisted Pair) construction offers enhanced protection against electromagnetic interference. This ensures that data transmissions remain stable and secure, even in environments with high levels of electrical noise.


    4.Operating at a frequency of 2000 MHz and boasting a data transfer rate of 40Gbps, this Cat8 Cable has the capacity to handle massive volumes of data at blazing speeds. It is thus well - suited for highly demanding applications such as seamless 4K video streaming, immersive online gaming experiences that require low latency, and quick large - file transfers.


    5.Encased in a durable PVC jacket, the cable is shielded from physical damage, abrasion, and environmental factors, ensuring a long lifespan. The PVC material also provides flexibility, facilitating easy installation in various networking scenarios.


    6.Whether you're in the process of building a new network infrastructure from the ground up or upgrading an existing one to meet the growing demands of digital operations, ITI-Link's Cat8 SFTP Shielded Ethernet Yellow Cable offers a dependable and efficient solution. Its versatility in handling different networking tasks and superior performance characteristics make it a preferred choice for IT professionals, network administrators, and any individual or organization aiming to maximize their network performance.



    FAQ:


    Q: What is the brand of this SFTP CAT8 Cable?

    A: The brand of this SFTP CAT8 Cable is ITI-LINK.


    Q: What is the model number of this SFTP CAT8 Cable?

    A: The model number of this SFTP CAT8 Cable is ITI-CTSF8-006.


    Q: Where is this SFTP CAT8 Cable manufactured?

    A: This SFTP CAT8 Cable is manufactured in SHENZHEN.


    Q: What is the maximum data transfer speed supported by this SFTP CAT8 Cable?

    A: This SFTP CAT8 Cable supports a maximum data transfer speed of 40Gbps.


    Q: Is this SFTP CAT8 Cable backward compatible with lower categories such as CAT6 or CAT5e?

    A: Yes, this SFTP CAT8 Cable is backward compatible with lower categories such as CAT6 or CAT5e.
